Sony ICF-CD543RM - Page 48

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
48
ICF-CD543RM
* 1-684-052-11 TRANSFORMER BOARD
*******************
1-533-233-31 HOLDER, FUSE (CND)
0 1-777-921-23 CORD, POWER (AEP)
0 1-783-817-51 CORD, POWER (US, CND)
< FUSE >
0F901 1-576-107-12 FUSE (3.15A/250V) (CND)
< CABLE HOLDER >
* KH901 1-573-287-11 HOLDER, CABLE 2P
< TRANSFORMER >
0T901 1-435-921-11 TRANSFORMER, POWER (AEP)
0T901 1-435-974-11 TRANSFORMER, POWER (US)
0T901 1-437-351-11 TRANSFORMER, POWER (CND)
< TERMINAL >
TM901 1-535-771-31 TERMINAL (AEP)
TM902 1-535-771-31 TERMINAL (AEP)
**************************************************************
MISCELLANEOUS
**************
10 1-823-760-11 CABLE, FLEXIBLE FLAT (14 CORE)
0108 1-777-921-23 CORD, POWER (AEP)
0108 1-783-817-51 CORD, POWER (US, CND)
151 1-757-689-11 CABLE, FLEXIBLE FLAT (16 CORE)
503 1-452-899-21 MAGNET
601 X-2162-708-1 CHASSIS ASSY (RCP) (RP),
MOTOR (SPINDLE) (including M701)
0605 8-820-161-02 OPTICAL PICK- UP (KSS-213R/C2RP)
0F901 1-576-107-12 FUSE (3.15A/250V) (CND)
M651 A-3320-538-A MOTOR ASSY, LOADING
M702 X-2162-712-1 GEAR ASSY (R) (RP), MOTOR (SLED)
SP101 1-529-478-11 SPEAKER (7.7cm)
SP201 1-529-478-11 SPEAKER (7.7cm)
0T901 1-435-921-11 TRANSFORMER, POWER (AEP)
0T901 1-435-974-11 TRANSFORMER, POWER (US)
0T901 1-437-351-11 TRANSFORMER, POWER (CND)
************************************************************
ACCESSORIES
************
3-009-707-01 SPACER
3-011-879-01 SCREW (M5X80), +B
3-238-070-21 BATTERY COVER (FOR RM-CD543A)
3-238-576-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, DUTCH) (CND, AEP)
3-238-576-21 MANUAL, INSTRUCTION (ENGLISH) (US)
3-238-576-31 MANUAL, INSTRUCTION (SWEDISH, DANISH,
FINNISH) (AEP)
* 3-897-241-01 CLAMP, CORD
A-3013-992-A REMOTE CONTROL UNIT (RM-CD543A)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
TRANSFORMER
Ver 1.1
