33
ICF-CD832
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R717 1-216-821-11 METAL CHIP 1K 5% 1/10W
R718 1-216-821-11 METAL CHIP 1K 5% 1/10W
R719 1-216-809-11 METAL CHIP 100 5% 1/10W
R720 1-216-809-11 METAL CHIP 100 5% 1/10W
R721 1-216-821-11 METAL CHIP 1K 5% 1/10W
R722 1-216-809-11 METAL CHIP 100 5% 1/10W
R723 1-216-809-11 METAL CHIP 100 5% 1/10W
R724 1-216-841-11 METAL CHIP 47K 5% 1/10W
R725 1-216-819-11 METAL CHIP 680 5% 1/10W
R726 1-216-819-11 METAL CHIP 680 5% 1/10W
R727 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R728 1-216-833-11 METAL CHIP 10K 5% 1/10W
R729 1-216-813-11 METAL CHIP 220 5% 1/10W
R730 1-216-821-11 METAL CHIP 1K 5% 1/10W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R732 1-216-841-11 METAL CHIP 47K 5% 1/10W
R741 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R743 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R744 1-216-845-11 METAL CHIP 100K 5% 1/10W
< SWITCH >
S701 1-571-936-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X701 1-781-801-21 VIBRATOR, CERAMIC (16.93MHz)
*************************************************************
* A-3347-592-A DRIVE BOARD, COMPLETE
**********************
< DIODE >
LED501 1-805-590-11 ELEMENT, LED INDICATOR (WHITE)
LED501 6-500-504-01 LED COG509T0A1 (BLACK)
< TRANSISTOR >
Q501 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q502 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q503 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q504 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q505 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q506 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q507 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q508 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q509 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q510 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q511 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q512 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q513 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q514 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q515 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q516 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
Q517 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
< RESISTOR >
R501 1-216-801-11 METAL CHIP 22 5% 1/10W
R502 1-216-801-11 METAL CHIP 22 5% 1/10W
R503 1-216-801-11 METAL CHIP 22 5% 1/10W
R504 1-216-801-11 METAL CHIP 22 5% 1/10W
R505 1-216-801-11 METAL CHIP 22 5% 1/10W
R506 1-216-801-11 METAL CHIP 22 5% 1/10W
R507 1-216-801-11 METAL CHIP 22 5% 1/10W
R508 1-216-801-11 METAL CHIP 22 5% 1/10W
R509 1-216-801-11 METAL CHIP 22 5% 1/10W
R510 1-216-801-11 METAL CHIP 22 5% 1/10W
R511 1-216-801-11 METAL CHIP 22 5% 1/10W
R512 1-216-801-11 METAL CHIP 22 5% 1/10W
R513 1-216-801-11 METAL CHIP 22 5% 1/10W
R514 1-216-801-11 METAL CHIP 22 5% 1/10W
R515 1-216-801-11 METAL CHIP 22 5% 1/10W
R516 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R517 1-216-817-11 METAL CHIP 470 5% 1/10W
R518 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R519 1-216-817-11 METAL CHIP 470 5% 1/10W
*************************************************************
* A-3347-607-A KEY (A) BOARD, COMPLETE
***********************
< CAPACITOR >
C601 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
* CN601 1-785-661-11 PIN, CONNECTOR (PC BOARD) 9P
< DIODE >
D601 6-500-033-01 LED TOL-50BHRBKEA-KS04 (SLEEP)
D602 6-500-033-01 LED TOL-50BHRBKEA-KS04 (NAP)
< TRANSISTOR >
Q601 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
Q602 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
< RESISTOR >
R601 1-216-849-11 METAL CHIP 220K 5% 1/10W
R602 1-216-853-11 METAL CHIP 470K 5% 1/10W
R603 1-216-849-11 METAL CHIP 220K 5% 1/10W
R604 1-216-845-11 METAL CHIP 100K 5% 1/10W
R605 1-216-845-11 METAL CHIP 100K 5% 1/10W
R606 1-216-841-11 METAL CHIP 47K 5% 1/10W
R608 1-216-837-11 METAL CHIP 22K 5% 1/10W
R609 1-216-841-11 METAL CHIP 47K 5% 1/10W
R610 1-216-837-11 METAL CHIP 22K 5% 1/10W
R612 1-216-833-11 METAL CHIP 10K 5% 1/10W
R613 1-216-809-11 METAL CHIP 100 5% 1/10W
R614 1-216-845-11 METAL CHIP 100K 5% 1/10W
R615 1-216-841-11 METAL CHIP 47K 5% 1/10W
R617 1-216-837-11 METAL CHIP 22K 5% 1/10W
R618 1-216-841-11 METAL CHIP 47K 5% 1/10W
R619 1-216-837-11 METAL CHIP 22K 5% 1/10W
R621 1-216-833-11 METAL CHIP 10K 5% 1/10W
R622 1-216-809-11 METAL CHIP 100 5% 1/10W
R623 1-216-841-11 METAL CHIP 47K 5% 1/10W
R624 1-216-841-11 METAL CHIP 47K 5% 1/10W
R625 1-216-841-11 METAL CHIP 47K 5% 1/10W
R626 1-216-837-11 METAL CHIP 22K 5% 1/10W
R627 1-216-837-11 METAL CHIP 22K 5% 1/10W
CD DRIVE KEY (A)
Ver 1.1
