34
ICF-CD832
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R628 1-216-837-11 METAL CHIP 22K 5% 1/10W
R629 1-216-837-11 METAL CHIP 22K 5% 1/10W
R630 1-216-837-11 METAL CHIP 22K 5% 1/10W
R631 1-216-809-11 METAL CHIP 100 5% 1/10W
R632 1-216-841-11 METAL CHIP 47K 5% 1/10W
R633 1-216-841-11 METAL CHIP 47K 5% 1/10W
R634 1-216-841-11 METAL CHIP 47K 5% 1/10W
R635 1-216-837-11 METAL CHIP 22K 5% 1/10W
R636 1-216-837-11 METAL CHIP 22K 5% 1/10W
R637 1-216-837-11 METAL CHIP 22K 5% 1/10W
R638 1-216-837-11 METAL CHIP 22K 5% 1/10W
R639 1-216-837-11 METAL CHIP 22K 5% 1/10W
R640 1-216-809-11 METAL CHIP 100 5% 1/10W
R641 1-216-817-11 METAL CHIP 470 5% 1/10W
R642 1-216-817-11 METAL CHIP 470 5% 1/10W
R643 1-216-841-11 METAL CHIP 47K 5% 1/10W
R644 1-216-841-11 METAL CHIP 47K 5% 1/10W
R645 1-216-841-11 METAL CHIP 47K 5% 1/10W
R646 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S601 1-786-050-21 SWITCH, KEYBOARD (OFF x•ALARM RESET)
S602 1-786-050-21 SWITCH, KEYBOARD (RADIO•ON)
S603 1-786-050-21 SWITCH, KEYBOARD (CD u)
S604 1-786-050-21 SWITCH, KEYBOARD (TIME SET –•.)
S605 1-786-050-21 SWITCH, KEYBOARD (SLEEP)
S606 1-786-050-21 SWITCH, KEYBOARD (SNOOZE/SLEEP OFF)
S607 1-786-050-21 SWITCH, KEYBOARD (ALARM SET A)
S608 1-786-050-21 SWITCH, KEYBOARD (NAP)
S609 1-786-050-21 SWITCH, KEYBOARD (TIME SET +•>)
S610 1-786-050-21 SWITCH, KEYBOARD (ALARM SET B)
S611 1-771-904-11 SWITCH, SLIDE (ALARM MODE (B))
S612 1-771-904-11 SWITCH, SLIDE (ALARM MODE (A))
*************************************************************
* A-3347-597-A KEY (B) BOARD, COMPLETE
***********************
< RESISTOR >
R651 1-216-841-11 METAL CHIP 47K 5% 1/10W
R652 1-216-841-11 METAL CHIP 47K 5% 1/10W
R653 1-216-841-11 METAL CHIP 47K 5% 1/10W
R654 1-216-837-11 METAL CHIP 22K 5% 1/10W
R655 1-216-837-11 METAL CHIP 22K 5% 1/10W
R656 1-216-837-11 METAL CHIP 22K 5% 1/10W
R657 1-216-837-11 METAL CHIP 22K 5% 1/10W
R658 1-216-837-11 METAL CHIP 22K 5% 1/10W
R659 1-216-809-11 METAL CHIP 100 5% 1/10W
R660 1-216-849-11 METAL CHIP 220K 5% 1/10W
R661 1-216-853-11 METAL CHIP 470K 5% 1/10W
R662 1-216-849-11 METAL CHIP 220K 5% 1/10W
R663 1-216-845-11 METAL CHIP 100K 5% 1/10W
< SWITCH >
S651 1-771-904-11 SWITCH, SLIDE (CD PLAY MODE)
S652 1-786-050-21 SWITCH, KEYBOARD (BRIGHTNESS)
S653 1-786-050-21 SWITCH, KEYBOARD (CLOCK/TRACK)
*************************************************************
* A-3347-588-A MAIN BOARD, COMPLETE (BLACK)
* A-4547-112-A MAIN BOARD, COMPLETE (WHITE)
*********************
1-501-907-51 ANTENNA, FM WIRE
3-243-251-01 CUSHION (LIGHT GUIDE PLATE)
3-248-348-01 HOLDER (ANTENNA)
* 3-248-354-01 PLATE (MAIN), SHIELD
* 3-249-185-01 PLATE (TUNER), SHIELD
3-382-175-41 KNOB (V)
3-831-441-11 CUSHION (B)
7-685-147-14 SCREW +P 3X10 TYPE2 NON-SLIT
< BPF >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C2 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C3 1-164-115-11 CERAMIC CHIP 5PF 0.25PF 50V
C4 1-164-115-11 CERAMIC CHIP 5PF 0.25PF 50V
C8 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C9 1-126-963-11 ELECT 4.7uF 20% 50V
C10 1-128-551-11 ELECT 22uF 20% 25V
C11 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C12 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C13 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C14 1-126-960-11 ELECT 1uF 20% 50V
C15 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C16 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C17 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C18 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C19 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C20 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-126-964-11 ELECT 10uF 20% 50V
C25 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C29 1-126-935-11 ELECT 470uF 20% 10V
C31 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C34 1-162-997-11 CERAMIC CHIP 10PF 0.5PF 50V
C35 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C36 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C37 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C101 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C103 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C104 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C105 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-126-961-11 ELECT 2.2uF 20% 50V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C110 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-916-11 ELECT 1000uF 20% 6.3V
C116 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C117 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C121 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
KEY (A) KEY (B) MAIN
