Sony ICF-SW10 - Page 13

Ref. No.
R25
R26
R27
R28
R29
R30
R31
R32
R33
R34
R35
R36
R37
RV1
RV2
Sl
S2
Tl
Part No. Description Remark
1-216-206-00 METAL GLAZE 2.2K 5% 1/8W
1-216-174-00 METAL GLAZE 100 oh 1/8W
1-216-234-00 METAL GLAZE 33K oh 1/8W
1-216-174-00 METAL GLAZE 100% 1/8W
1-216-001-00 METAL CHIP 10 5h 1/10W
1-216-093-00 METAL CHIP 68K 5% 1/10W
1-216-093-00 METAL CHIP 68K o% 1/10W
1-216-093-00 METAL CHIP 68K oh 1/10W
1-216-033-00 METAL CHIP 220 Ot 1/10W
1-216-099-00 METAL GLAZE 120K 5% 1/10W
1-216-049-00 METAL GLAZE 1K oh 1/10¥
1-216-049-00 METAL GLAZE 1K 4h 1/100
1-216-037-00 METAL GLAZE 330 5k 1/10¥
< VARIABLE RESISTOR >
1-228-995-00 RES, ADJ, METAL 22K
1-238-555-11 RES, VAR, CARBON 50K (VOLUME)
< SWITCH >
1-692-846-11 SWITCH, SLIDE (BAND)
1-571-850-81 SWITCH, SLIDE (POWER)
< TRANSFORMER >
1-416-021-11 COIL (AM IFT) (455KHz)
SERRE CRC ACR I 2K KK RRC AE AC OE A AC A CO 9 9 IE AC RE A of EH 2k
ANT1
SP901
MISCELLANEOUS
FRR RR a
1-501-222-71 ANTENNA, TELESCOPIC (FM)
1-544-517-11 SPEAKER
SORA CR HOR CAR OK IC ACK CO ICR CC CK A 9 CR Ne 2 CC IE EI CO 2 2 2 2 oe 9 ok 2
*
*
ACCESSORIES & PACKING MATERIALS
2G RE a AG 2 2K I EK ie i fe of 2: 2c fe 2 26 2 2 2 2k
3-758-269-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH, GERMAN,
SPANISH, DUTCH, SWEDISH, ITALIAN PORTUGUESE)
(EXCEPT Saudi Arabia)
3-758-269-71 MANUAL, INSTRUCTION (ENGLISH, FRENCH, GERMAN,
SPANISH, DUTCH, ARABIC, ITALIAN, PORTUGUESE)
(Saudi Arabia)
3-912-863-01 GUIDE, SHOOT WAVE
3-913-013-01 INDIVIDUAL CARTON
FEO OR ICR ROR IOI IK CR aR ok a aK aC a I ICRC oC CAC 2K CE AC AE 2 AE AE a IE a
#1
#2
#3
SI HC a a A a ACI EE
HARDWARE LIST
SIG Kk CR ROK
7-685-105-19 TPG +P 2X8, TYPE 2 N-S
7-685-138-19 SCREW +P 2,6X16 TYPE 2 N-S
7-685-534-19 SCREW +BIP 2,6X8 TYPE 2 N-S
