34
Mirror: The mirror stores the images reflected by it so it can be used for
surveillance or to simply take your own picture.
Flip: To flip the camera’s lens 180 degrees.
Power Line Select 50 Hz or 60Hz that depends on your local electric utility
configuration.
White Balance White balance is the process of removing unnatural shades of color, so that
objects which appear white in reality are rendered white in the images.
Select your options from “Auto”, “Outdoor”, “Indoor” and “Fluorescent”.
Brightness: An adjustable setting to compensate for backlit scenes.
Contrast: The measurement for color intensity/strength.
Saturation: This setting controls the strength of colors from black and white to bold
colors.
Sharpness An adjustable setting to set the clarity of detail in the images.
WDR Level The Wide Dynamic Range (WDR) function of a camera is intended to
provide clear images even under back light circumstances. WDR enables
the capture and display of both bright areas and dark areas in the same
frame, in a way that there are details in both areas, i.e. bright areas are not
saturated, and dark areas are not too dark. Select your options of the level
between 0 and 8. 0 is the lowest level and 8 is the highest one.
Timestamp Color: Click to open the list of five color modes to choose from: “WHITE”,
“BLACK”, “GREEN”, “BLUE”, and “ORANGE”.
Timestamp Location: Click to open the list of four location modes to choose from: “UPPER
LEFT”, “UPPER RIGHT”, “BOTTOM LEFT”, and “BOTTOM RIGHT”.
Timestamp Format: Click to open the list of six format modes to choose from: “YYYY/MM/DD”,
“MM/DD/YYYY”, “DD/MM/YYYY”, “YYYY/MM/DD TITLE”, “MM/DD/YYYY
TITLE”, “DD/MM/YY TITLE”, “TITLE YYYY
