SECTION 3

TROUBLESHOOTING

2.3.6 HDMI Failure(No Picture) – Main board analysis Flowchart

Main Board Failure

(No Picture)

Check +5V power

(spec4.8~5.3V)

+5V FA Flow

Yes

Check HPD Voltage Level

(spec4.8~5.3V)

Yes

Check I

C Voltage Level

(spec 5V)

HPD FA Flow

C FA Flow

Change Main Board

END
