ESD wrist-strap

ESD wrist-strap to be checked daily.

Use Multi-meter to make sure resistance of ESD wrist-strap is OK.

(R=750K Ohms to 35Mega Ohms)

ESD cushion/sheet

Please use a bag containing the board or a special seat

※Things to prepare in advance

1) Caution for Board handling(Stress)

Be sure to observe the following contents.

③ Handle with care. Do not swing.

① Hold the board with both hands

② Do not hold/push Heat-Sink

SECTION 1

SAFETY NOTES

SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAMS PANEL HANDLING FACTORY DATA RESET
