49
4. UNLOCK THE SCREWS.
SCREW SILVER/M2.5 x 6 Ni/C1018
21PCS
SCREW SILVER/M2.5*L10 Ni/C1018
3PCS
DISASSEMBLY AND PARTS LIST
KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
