Chapter 2 - Service and Troubleshooting
CTV-41 24
26"/32" S SERIES CIRCUIT BOARD LOCATIONS
INVERTER
G1D 26"
G1H 32"
BU1
U1
TCON
FIGURE 2-1
26” AND 32” S SERIES CIRCUIT BOARD LOCATIONS
