CTV41 66
Chapter 3. Disassembly
46” Panel Removal
Removal of a 46” panel is similar to the procedures for a 26’ or 32” panel
and also applies to the 40” panel. The wall mount brackets will be left
intact because the entire panel and sub-chassis with circuit boards will be
lifted from the bezel. After this is done, the sub-chassis assemblies and
circuit boards will be removed from the LCD panel and transferred to the
replacement unit. The steps required to do this are shown in Figures 3-8
through 3-13.
