CTV41 65
Chapter 3. Disassembly
FIGURE 3-7
26/32 LCD PANEL REMOVAL (STEP 5)
TRANSFER BRACKET ASSEMBLY TO
REPLACEMENT PANEL
FIGURE 3-7
26/32” PANEL REMOVAL (STEP 5)
