Chapter 2 - Service and Troubleshooting
CTV-41 27
46" CIRCUIT BOARD LOCATION
BALANCER
G3
BU1
U1
TCON
D1
D2
BALANCER
FIGURE 2-4
46S3000 CIRCUIT BOARD LOCATIONS
