Chapter 2 - Service and Troubleshooting
CTV-41 37
FIGURE 2-10
QM TEST PATTERN GRAPHICS
DATA SETTING
CHANGES
GRAPHICS
PAGE 1 BRINGS UP
QM GRAPHICS
FIGURE 2-10
QM (ATI MICRO) SERVICE GRAPHICS
