Chapter 3. Disassembly
FIGURE 3-9
40/46” PANEL REMOVAL (STEP 2)
FIGURE 3-9
40/46" PANEL REMOVAL (STEP 2)
REMOVE 2 SCREWS
SECURING TOP
BRACKET
UNPLUG CN101 AND
REMOVE H1 BOARD
