Sony KDL-26S3000 Training Manual

CTV41 71
Chapter 3. Disassembly
FIGURE 3-12
40/46" PANEL REMOVAL (STEP 5)
REMOVE 8 MACHINE SCREWS SECURING
WALL MOUNT BRACKETS TO PANEL
IMPORTANT! THESE SCREWS ARE VERY
SHORT SO AS TO NOT PENETRATE DEEPLY
INTO THE PANEL
FIGURE 3-12
40/46” PANEL REMOVAL (STEP 5)
