KDL-32/40EX720,721,723,724(AEP/UK)
57
TROUBLE SHOOTING
2) 3 times blinking (DC Alert, Audio Error and Communication Error)
3 times blinking
Check D+1.2V at
pin14 of IC6005
on the B* Board
F6001,IC6005,etc
(B* Board)
Speaker
Check +3.3V_MAIN
at pins 9/10 of CN9003
on the B* Board
Check
Speaker Impedance
at SP Connector
F6003,IC6003,etc
(B* Board)
Check AUDIO+12.5V
at pins 8/9 of
CN6001 on
the B* Board
G* Board
Check +12.5V
at F4601 on
the B* Board
F4601,IC4601,etc
(B* Board)
IC4601,etc
(B* Board)
DC_ALERT
NG
OK
AUDIO
AUDIO
FE/BE Communication
NG
OK
NG
OK
NG
OK
NG
OK
