KDL-32/40EX720,721,723,724(AEP/UK)
88
APPENDIX-1
1
2
3
Push
2
3
1
2
3
Please lift Up
the minimum.
Insert plastic part (less than 15mm)
*Do not use metal one.
*Take care not to scratch parts.
Notice:
6
6
5
4
3
2
1
PROCEDURE TO REMOVE THE REAR COVER (32)
1. Remove all the screws on the Rear Cover and the AC Cover.
2. Open the Rear Cover in the order as shown below.
To Next Page
