KDL-32/40EX720,721,723,724(AEP/UK)
90
5
55555
4
3
1
2
PROCEDURE TO REMOVE THE REAR COVER (40)
1. Remove all the screws on the Rear Cover and the AC Cover.
2. Open the Rear Cover in the order as shown below.
Note: Do not open quickly when hooks 1~5 are locked.
This hook is automatically
released .
Notice:
Insert your hand in the place shown in picture.
Insert your hand below screw hole as shown in picture.
Open RC slowly with care.
1
2
APPENDIX-1
