Sony KDL-40D340 - 1 General; Special Note for Models Using Type a and Type S Panels

- 3 -
WAX3F
RM-ED009
WAX3F-LC models use both Type A and Type S panels. The table below indicates which models use the various panels. In some cases models
have used both panels. In this case the serial numbers are shown under the appropriate panel heading to indicate which panel was used at that
particular serial number. The correct panel must be used when carrying out a replacement.
WAX3F-LC Model List
SECTION 1 GENERAL
SPECIAL NOTE FOR MODELS USING TYPE A AND TYPE S PANELS
For serial numbers beginning 45, the type of panel is indicated by the fifth digit.
eg. 45xx0xx = Type A Panel
45xx1xx = Type S Panel
For serial numbers beginning 40, 41, 43 or 44, the type of panel is indicated by the second digit.
eg. 40xxxxx = Type A Panel
41xxxxx = Type S Panel
43xxxxx = Type A Panel
44xxxxx = Type S Panel
Model Name Destination
Type A Panel Type S Panel
F-No. Serial No. F-No. Serial No.
KDL-40D3550 UK
17-7517-00 - 4000001~4099999 17-7576-00 4500101-4500101 4100001~4199999
KDL-40D3550 AEP
17-7518-00 4530001~4530013 4300001~4399999 17-7577-00 4530101~4530101 4400001~4499999
KDL-46D3550 UK
17-7519-00 - 4000001~4099999 * * *
KDL-46D3550 AEP
17-7520-00 4530001~4530008 4300001~4399999 * * *
KDL-40D3500 UK
17-7521-00 4500001~4500016 4000001~4099999 17-7580-00 4500101-4500104 4100001~4199999
KDL-40D3500 AEP
17-7522-00 4530001~4530032 4300001~4399999 17-7581-00 4530101~4530101 4400001~4499999
KDL-46D3500 UK
17-7523-00 4500001~4500015 4000001~4099999 * * *
KDL-46D3500 AEP
17-7524-00 4530001~4530037 4300001~4399999 * * *
KDL-40D3400 AEP
17-7539-00 4530001~4530002 4300001~4399999 17-7584-00 4530101~4530103 4400001~4499999
KDL-46D3400 AEP
17-7540-00 4530001~4530002 4300001~4399999 * * *
KDL-40D3660 AEP
17-7541-00 4530001~4530002 4300001~4399999 17-7586-00 4530101~4530102 4400001~4499999
KDL-46D3660 AEP
17-7542-00 4530001~4530002 4300001~4399999 * * *
