Difference List for Models using Type A and Type S Panels
The table below indicates the differnces for models using the various panels. This table must be followed when replacing the panels or BE1F
boards in these models.
Panel Type A Panel Type S Panel
1. Panel
Panel Kit
A-1317-406-A (40 inches)
A-1317-407-A (46 inches)
A-1379-331-A (40 inches)
Panel
(1-802-580-11) (40 inches)
(1-802-579-11) (46 inches)
(1-802-488-13) (40 inches)
2. BE1F (Service)
Model Name Destination
F-No. A-No. Name F-No. A-No.
KDL-40D3550 UK 17-7517-00
A-1487-854-C
BE1F COMPLETE
(40" DF SERVICE)
17-7576-00
A-1506-863-B
BE1F COMPLETE
(40" DFSL SERVICE)
KDL-40D3550 AEP
17-7518-00 17-7577-00
KDL-40D3660 AEP
17-7541-00 17-7586-00
KDL-46D3550 UK
17-7519-00
A-1487-855-C
BE1F COMPLETE
(46" DF SERVICE)
None * *KDL-46D3550 AEP 17-7520-00
KDL-46D3660 AEP
17-7542-00
KDL-40D3500 UK
17-7521-00
A-1487-856-C
BE1F COMPLETE
(40" DB SERVICE)
17-7580-00
A-1506-864-B
BE1F COMPLETE
(40" DBSL SERVICE)
KDL-40D3500 AEP
17-7522-00 17-7581-00
KDL-40D3400 AEP
17-7539-00 17-7584-00
KDL-46D3500 UK
17-7523-00
A-1487-857-C
BE1F COMPLETE
(46" DB SERVICE)
None * *KDL-46D3500 AEP 17-7524-00
KDL-46D3400 AEP
17-7540-00
3. Software Version
Software Package Version
PKG 1. 0xx_N_LC_32M_ADJ PKG 1. 5xx_N_LC_32M_ADJ
4. LVDS Harness
Lead wire with connector (LVDS)
1-834-589-11 (40 inches)
1-834-590-11 (46 inches)
1-834-983-11 (40 inches)
5. SHEET(CORE), C 2pcs (Addition)
SHEET(CORE), C
4-100-136-01 : 7 pcs (40 inches)
: 15 pcs (46 inches)
4-100-136-01 : 9 pcs (40 inches)
6. INSULATING SHEET 2pcs (Addition)
INSULATION SHEET
None 3-290-717-01 : 2 pcs (40 inches)
7. SPRING, PANEL(26) 2pcs (Addition)
SPRING, PANEL (26)
None 2-682-457-01 : 2 pcs (40 inches)
