KDL-HX751/HX750
4-411-895-11(1)
33
Additional
Information
Specifications
System
Television system NTSC: American TV standard
ATSC (8VSB terrestrial): ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality)
Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69
Analog Cable: 1 - 135 / Digital Cable: 1 - 135
Panel system LCD (Liquid Crystal Display) Panel
Speaker output 10 W + 10 W
Input/Output jacks
CABLE/ANTENNA 75-ohm external terminal for RF inputs
VIDEO IN 1 Video / Audio input (phono jacks)
COMPONENT IN
VIDEO IN 2
YP
BPR (Component Video): 1080p (60 Hz), 1080i (60 Hz), 720p (60 Hz), 480p, 480i
Audio input (phono jacks)
Video input (common phono pin with Y input)
HDMI IN 1/2/3/4 Video (2D): 1080p (30, 60 Hz), 1080/24p, 1080i (60 Hz), 720p (30, 60 Hz), 720/24p,
480p, 480i, PC Formats
Video (3D):
Frame Packing 1080p (30 Hz), 1080/24p, 1080i (60 Hz), 720p (30, 60 Hz), 720/24p
Side-by-Side 1080p (60 Hz), 1080/24p, 1080i (60 Hz), 720p (60 Hz)
Over-Under 1080p (30, 60 Hz), 1080/24p, 1080i (60 Hz), 720p (60 Hz)
Audio: Two channel linear PCM: 32, 44.1 and 48 kHz, 16, 20 and 24 bits, Dolby Digital
Analog audio input (stereo mini jack) (HDMI IN 2 only, common with PC IN)
ARC (Audio Return Channel) (HDMI IN 1 only)
AUDIO OUT/Headphones Stereo mini jack
DIGITAL AUDIO OUT
(OPTICAL)
Digital optical jack (Two channel linear PCM, Dolby Digital)
PC IN
PC/HDMI 2 AUDIO IN
Analog RGB (Mini D-sub 15-pin)
Audio input (stereo mini jack) (common with HDMI IN 2)
LAN 10BASE-T/100BASE-TX connector (Connection speed may differ depending on the
network environment. 10BASE-T/100BASE-TX communication rate and
communication quality are not guaranteed for this TV.)
USB/DLNA Refer to the i-Manual for supported format.
Model name KDL- 55HX751
55HX750
46HX751
46HX750
Power and others
Power requirement 110-240 V AC, 50/60 Hz (U.S.A./Canada 120 V AC, 60 Hz)
Power
consumption
in use 141 W 132 W
in DAM*
0.02 kWh/Day
(You may hear a clicking noise during the download but this is normal.)
in standby Less than 0.15 W with 120 V AC and less than 0.3 W with 240 V AC
Screen size
(inches measured diagonally)
54.6 inches
(55 class)
46 inches
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Dimensions with stand (mm)
(inches)
1,271 × 798 × 312
50
1
/
8
× 31
1
/
2
× 12
3
/
8
1,076 × 687 × 252
42
3
/
8
× 27
1
/
8
× 10
without stand
(mm)
(inches)
1,271 × 761 × 60
50
1
/
8
× 30 × 2
3
/
8
1,076 × 650 × 60
42
3
/
8
× 25
5
/
8
× 2
3
/
8
wall-mount hole
pattern (mm) 300 × 300
wall-mount screw
size (mm)
M6 (length: see diagram on page 20.)
Mass with stand
(kg)/(lb.)
23.6 / 52.0 17.6 / 38.8
without stand
(kg)/(lb.)
19.2 / 42.3 14.6 / 32.2
Supplied accessories See page 8 (Checking the accessories).
(Continued)
