Installing the TV Against a
Wall or Enclosed Area
Make sure that your TV has adequate
ventilation. Allow enough space around the
TV as shown in the illustration.
~
• Inadequate ventilation can lead to overheating
of the TV and may cause damage to your TV
or cause a fire.
(30 cm)
11
7
/
8
inches
(6 cm)
inches
4 inches
(10 cm)
4 inches
(10 cm)
2
3
/
8
Leave at least this much space around the set.
Installed with stand
inches
11
7
/
8
4 inches
(10 cm)
4 inches
(10 cm)
4 inches (10 cm)
(30 cm)
Installed on the wall
Leave at
least this
much space
around the
set.
Never install the TV set as follows:
Air circulation is blocked. Air circulation is blocked.
Wall Wall
