KDL-60/55/46NX720/55/46HX820/XBR-65/55/46HX929
4-270-401-13(1)
*1 For HX929 model series, when Control4 is set to On, control by BRAVIA Sync will be disabled.
*2 Download Acquisition Mode (DAM) is used for software updates and/or collecting data for Rovi
On Screen Guide.
• Optional accessories availability depends on its stock.
• Design and specifications are subject to change without notice.
Mass with stand (kg)/(lb.) 51.7 / 113.8 34.5 / 76.0 31.6 / 69.7 28.3 / 62.4 28.3 / 62.4
without stand (kg)/(lb.) 43.2 / 95.1 28.8 / 63.5 26.1 / 57.5 23.2 / 51.2 23.1 / 50.9
Supplied accessories See “Checking the accessories” (page 8).
Optional accessories Connecting cables
Support Belt Kit
Wall-Mount Bracket: SU-WL700 (except XBR-65HX929, KDL-60NX720)
SU-WL500
Wall-Hanging Bracket: SU-WH500 (except XBR-65HX929)
TV Stand: SU-B551S (XBR-55HX929, KDL-55HX820, KDL-55NX720)
3D Glasses: TDG-BR250/TDG-BR200/TDG-BR100/TDG-BR50
Camera and Microphone Unit: CMU-BR100
USB Wireless LAN Adapter
Operating temperature 32 ºF – 104 ºF (0 ºC – 40 ºC)
Model name KDL-/XBR- 65HX929 60NX720 55HX929 55HX820 55NX720
Model name KDL-/XBR- 46HX929 46HX820 46NX720
Power and others
Power requirement 110-240 V AC, 50/60 Hz (U.S.A./Canada 120 V AC, 60 Hz)
Power consumption
138 W 142 W 123 W
in use
in DAM*
2
0.02 kWh/Day
(You may hear a clicking noise during the download but this is normal.)
in standby
Less than 0.2 W with 120 V AC and less than 0.4 W with
240 V AC
Less than 0.2 W with 120 V
AC and less than 0.3 W with
240 V AC
Screen size
(inches measured diagonally)
46 inches
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Speaker
Full range (mm)
(inches)
Woofer (mm)
(inches)
30 × 150 (2)
1
3
/
16
× 6 (2)
) 60 (1)
) 2
3
/
8
(1)
20 × 75 (4)
13
/
16
× 3 (4)
40 × 90 (1)
1
5
/
8
× 3
5
/
8
(1)
20 × 90 (2)
13
/
16
× 3
5
/
8
(2)
) 60 (1)
) 2
3
/
8
(1)
Dimensions with stand (mm)
(inches)
1,081 × 692 × 258
42
5
/
8
× 27
1
/
4
× 10
1
/
4
1,083 × 693 × 255
42
5
/
8
× 27
3
/
8
× 10
1
/
8
1,084 × 694 × 258
42
3
/
4
× 27
3
/
8
× 10
1
/
4
without stand (mm)
(inches)
1,081 × 660 × 38
42
5
/
8
× 26 × 1
1
/
2
1,083 × 663 × 27
42
5
/
8
× 26
1
/
8
× 1
1
/
8
1,084 × 663 × 27
42
3
/
4
× 26
1
/
8
× 1
1
/
8
wall-mount hole pattern
(mm)
300 × 300
wall-mount screw size
(mm)
M6 (length: refer to diagram on page 21.)
Mass with stand (kg)/(lb.) 24.0 / 52.9 21.1 / 46.5 20.2 / 44.5
without stand (kg)/(lb.) 19.4 / 42.8 16.8 / 37.1 15.8 / 34.8
Supplied accessories See “Checking the accessories” (page 8).
Optional accessories Connecting cables
Support Belt Kit
Wall-Mount Bracket: SU-WL700/SU-WL500
Wall-Hanging Bracket: SU-WH500
TV Stand: SU-B461S
3D Glasses: TDG-BR250/TDG-BR200/TDG-BR100/TDG-BR50
Camera and Microphone Unit: CMU-BR100
USB Wireless LAN Adapter
Operating temperature 32 ºF – 104 ºF (0 ºC – 40 ºC)
