Sony KLV-32M400A - G1 D Parts List; G2 D Parts List

KLV-26M400A/32M400A/37M400A/40M400A
KLV-26M400A/32M400A/37M400A/40M400A
74
REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
RB4909 1-234-370-21 RES, NETWORK 22 (1005X4)
RB4910 1-234-370-21 RES, NETWORK 22 (1005X4)
RB4911 1-234-370-21 RES, NETWORK 22 (1005X4)
RB5001 1-239-698-11 RESISTOR, NETWORK 10K
RB5002 1-239-670-81 RESISTOR, NETWORK 47
RB5504 1-239-674-81 RESISTOR, NETWORK 100
RB5505 1-239-674-81 RESISTOR, NETWORK 100
RB5507 1-239-670-81 RESISTOR, NETWORK 47
RB5508 1-239-706-81 RESISTOR, NETWORK 47K
RB5509 1-239-698-11 RESISTOR, NETWORK 10K
RB5510 1-239-706-81 RESISTOR, NETWORK 47K
RB5511 1-239-706-81 RESISTOR, NETWORK 47K
RB5512 1-234-369-21 RES, NETWORK 10 (1005X4)
RB5513 1-234-369-21 RES, NETWORK 10 (1005X4)
RB5514 1-234-369-21 RES, NETWORK 10 (1005X4)
RB5515 1-234-369-21 RES, NETWORK 10 (1005X4)
TUNER
TU7001 8-597-611-00 TUNER, FSS BTF-CA411Z
VARISTOR
VD1001 1-802-078-11 VARISTOR (SMD)
VD1002 1-802-078-11 VARISTOR (SMD)
VD1005 1-802-078-11 VARISTOR (SMD)
VD1006 1-802-078-11 VARISTOR (SMD)
VD1106 1-802-078-11 VARISTOR (SMD)
VD1107 1-802-078-11 VARISTOR (SMD)
VD1108 1-802-078-11 VARISTOR (SMD)
VD1109 1-802-078-11 VARISTOR (SMD)
VD1110 1-802-078-11 VARISTOR (SMD)
VD1111 1-802-078-11 VARISTOR (SMD)
VD1112 1-802-078-11 VARISTOR (SMD)
VD1113 1-802-078-11 VARISTOR (SMD)
VD1114 1-802-078-11 VARISTOR (SMD)
VD1115 1-802-078-11 VARISTOR (SMD)
VD1200 1-802-078-11 VARISTOR (SMD)
VD1201 1-802-078-11 VARISTOR (SMD)
VD1702 1-802-078-11 VARISTOR (SMD)
VD1703 1-802-078-11 VARISTOR (SMD)
VD1710 1-802-078-11 VARISTOR (SMD)
VD1711 1-802-078-11 VARISTOR (SMD)
VD1720 1-802-078-11 VARISTOR (SMD)
VD1721 1-802-078-11 VARISTOR (SMD)
VD2001 1-802-078-11 VARISTOR (SMD)
VD2002 1-802-078-11 VARISTOR (SMD)
VD2003 1-802-078-11 VARISTOR (SMD)
VD5002 1-802-078-11 VARISTOR (SMD)
VD5003 1-802-078-11 VARISTOR (SMD)
VD5004 1-802-078-11 VARISTOR (SMD)
VD5005 1-802-078-11 VARISTOR (SMD)
VD5006 1-802-078-11 VARISTOR (SMD)
VD5501 1-805-774-21 VARISTOR, CHIP
VD5503 1-802-417-11 SURGE ABSORBER
VD5506 1-802-417-11 SURGE ABSORBER
VD5509 1-802-417-11 SURGE ABSORBER
VD5513 1-802-417-11 SURGE ABSORBER
VD5517 1-802-417-11 SURGE ABSORBER
VD5519 1-802-481-11 ESD SUPPRESSOR (4 ARRAY)
VD5520 1-802-481-11 ESD SUPPRESSOR (4 ARRAY)
VD5521 1-802-481-11 ESD SUPPRESSOR (4 ARRAY)
VD5522 1-802-481-11 ESD SUPPRESSOR (4 ARRAY)
CRYSTAL
X2001 1-813-462-11 VIBRATOR, CRYSTAL 24.576MHZ
X3001 1-813-070-21 PIEZOELECTRIC OSCILLATOR
X3009 1-813-784-21 VIBRATOR, CRYSTAL
X4500 1-813-773-11 VIBRATOR, CRYSTAL
G1D
1-474-096-11 G1D BOARD (POWER UNIT)
(KLV-26M400A ONLY)
1-474-099-11 G1D BOARD (POWER UNIT)
(KLV-32M400A ONLY)
This board is manufactured by a 3rd party.
Component level repair information is not available.
G2D
1-474-095-12 G2D BOARD (POWER UNIT)
(KLV-37M400A ONLY)
This board is manufactured by a 3rd party.
Component level repair information is not available.
BG2A
G1D G2D
