Sony KLV-32M400A - Page 75

KLV-26M400A/32M400A/37M400A/40M400A
KLV-26M400A/32M400A/37M400A/40M400A
75
REF. NO.ART NO. DESCRIPTION VALUES
REF. NO.ART NO. DESCRIPTION VALUES
HM4
A-1543-346-A HM4 (VAR) BOARD, MOUNTED
CAPACITOR
C320 1-112-781-11 CERAMIC CHIP 1μF 10% 10V
C322 1-107-826-11 CERAMIC CHIP 0.1μF 10% 16V
C323 1-126-205-11 ELECT CHIP 47μF 20% 6.3V
C401 1-162-960-11 CERAMIC CHIP 220pF 10% 50V
C402 1-100-909-11 CERAMIC CHIP 10μF 10% 6.3V
CONNECTOR
* CN301 1-820-287-11 HEADER ASSEMBLY (PRINT PWB)
DIODE
D305 8-719-085-26 DIODE CL-165HR/SYG-D-T
D308 8-719-053-07 DIODE SML-310MTT86
D321 6-500-817-01 DIODE (LED) SML-512UWT86
D322 8-719-036-94 DIODE RD5.6SB-T1
IC
IC402 6-600-688-01 IC KSM-511M2Q
TRANSISTOR
Q303 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q304 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q305 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q320 6-551-699-01 TRANSISTOR ISA1602AM1TP-1EF
Q321 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q322 8-729-028-96 TRANSISTOR DTC114EUA-T106
RESISTOR
R303 1-216-815-11 METAL CHIP 330 5% 1/10W
R304 1-216-819-11 METAL CHIP 680 5% 1/10W
R305 1-216-815-11 METAL CHIP 330 5% 1/10W
R321 1-216-839-11 METAL CHIP 33K 5% 1/10W
R322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R323 1-216-833-11 METAL CHIP 10K 5% 1/10W
R325 1-216-864-11 SHORT CHIP
R326 1-216-847-11 METAL CHIP 150K 5% 1/10W
R328 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R329 1-216-819-11 METAL CHIP 680 5% 1/10W
R330 1-216-835-11 METAL CHIP 15K 5% 1/10W
R332 1-216-864-11 SHORT CHIP
R401 1-216-817-11 METAL CHIP 470 5% 1/10W
R402 1-216-805-11 METAL CHIP 47 5% 1/10W
IP5Z
A-1493-910-D IP5Z BOARD, COMPLETE
(KLV-40M400A ONLY)
2-580-592-01 SCREW, +PSW M3X8
CAPACITOR
C6002 1-165-529-11 MYLAR 0.22μF 10 275V
C6006 1-112-876-51 CERAMIC 470pF 10% 250V
C6007 1-112-874-51 CERAMIC 220pF 10% 250V
C6010 1-112-876-51 CERAMIC 470pF 10% 250V
C6011 1-112-874-51 CERAMIC 220pF 10% 250V
C6014 1-161-964-91 CERAMIC 0.0047μF 250V
C6015 1-161-964-91 CERAMIC 0.0047μF 250V
C6018 1-165-529-11 MYLAR 0.22μF 10 275V
C6020 1-114-323-11 CERAMIC CHIP 0.01μF 10% 50V
C6024 1-112-876-51 CERAMIC 470pF 10% 250V
C6100 1-114-323-11 CERAMIC CHIP 0.01μF 10% 50V
C6101 1-100-831-91 CERAMIC CHIP 0.001μF 2% 50V
C6102 1-107-906-11 ELECT 10μF 20% 50V
C6103 1-107-905-11 ELECT 4.7μF 20% 50V
C6104 1-107-910-11 ELECT 100μF 20% 50V
C6106 1-114-323-11 CERAMIC CHIP 0.01μF 10% 50V
C6107 1-107-888-11 ELECT 47μF 20% 25V
C6108 1-114-326-11 CERAMIC CHIP 0.22μF 10% 25V
C6110 1-112-481-11 CERAMIC 470pF 10% 1KV
C6111 1-100-732-11 FILM 18000pF 3% 1KV
C6150 1-114-328-11 CERAMIC CHIP 0.047μF 10% 50V
C6152 1-112-229-21 ELECT 1500μF 20% 16V
C6153 1-112-229-21 ELECT 1500μF 20% 16V
C6155 1-114-323-11 CERAMIC CHIP 0.01μF 10% 50V
C6159 1-112-835-11 ELECT 3300μF 20% 25V
C6161 1-114-324-11 CERAMIC CHIP 0.022μF 10% 50V
C6200 1-114-325-11 CERAMIC CHIP 0.1μF 10% 25V
C6201 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C6202 1-107-902-11 ELECT 1μF 20% 50V
C6203 1-100-139-31 FILM 0.001μF 5% 630V
HM4
IP5Z
