Sony KV-EF34M31 - Board V1 Component List

REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
Les composants identifies par
une trame et une marque !
sont critiques pour la securite.
Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark ! are criti-
cal for safety.
Replace only with part number
specified.
-------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------------------------------------------
-------------------
KV-EF34M31/EF34M61/EF34M80/EF34M90/EF34M91
RM-951
– 131 –
*A-1342-452-A V1 BOARD, COMPLETE
**********************
(KV-EF34M31/EF34M61/EF34M91)
<CAPACITOR>
C801 1-104-664-11 ELECT 47MF 20% 16V
C805 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C806 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C815 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C816 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C817 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C818 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C820 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C821 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C822 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C823 1-126-933-11 ELECT 100MF 20% 16V
C826 1-126-963-11 ELECT 4.7MF 20% 50V
C829 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C830 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C831 1-126-933-11 ELECT 100MF 20% 16V
C832 1-126-964-11 ELECT 10MF 20% 50V
C835 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C837 1-126-933-11 ELECT 100MF 20% 16V
<CONNECTOR>
CN801 * 1-774-812-11 CONNECTOR, BOARD TO BOARD 7P
CN803 * 1-774-812-11 CONNECTOR, BOARD TO BOARD 7P
<DIODE>
D802 8-719-914-44 DIODE DAP202K
D803 8-719-105-46 DIODE RD3.3M-B2
D804 8-719-105-91 DIODE RD5.6M-B2
D806 8-719-404-49 DIODE MA111
D807 8-719-404-49 DIODE MA111
<FERRITE BEAD>
FB801 1-410-397-21 FERRITE 1.1UH
FB802 1-410-397-21 FERRITE 1.1UH
FB803 1-410-397-21 FERRITE 1.1UH
FB804 1-410-682-31 INDUCTOR 470UH
FB805 1-410-397-21 FERRITE 1.1UH
<IC>
IC801 8-759-476-87 IC SAA5261
<CHIP CONDUCTOR>
JR801 1-216-295-91 SHORT 0
JR802 1-216-295-91 SHORT 0
JR804 1-216-295-91 SHORT 0
JR805 1-216-295-91 SHORT 0
JR806 1-216-295-91 SHORT 0
JR807 1-216-295-91 SHORT 0
JR808 1-216-295-91 SHORT 0
<TRANSISTOR>
Q801 8-729-230-49 TRANSISTOR 2SC2712-YG
Q803 8-729-230-49 TRANSISTOR 2SC2712-YG
Q805 8-729-230-49 TRANSISTOR 2SC2712-YG
Q806 8-729-230-49 TRANSISTOR 2SC2712-YG
Q807 8-729-230-49 TRANSISTOR 2SC2712-YG
Q808 8-729-230-49 TRANSISTOR 2SC2712-YG
Q810 8-729-230-49 TRANSISTOR 2SC2712-YG
Q811 8-729-019-01 TRANSISTOR 2SD2394-EF
Q812 8-729-230-49 TRANSISTOR 2SC2712-YG
Q813 8-729-230-49 TRANSISTOR 2SC2712-YG
Q814 8-729-230-49 TRANSISTOR 2SC2712-YG
Q817 8-729-900-53 TRANSISTOR DTC114EK
Q818 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
R800 1-208-806-11 RES,CHIP 10K 0.50% 1/10W
R801 1-216-295-91 SHORT 0
R802 1-216-025-91 RES,CHIP 100 5% 1/10W
R803 1-216-295-91 SHORT 0
R804 1-216-295-91 SHORT 0
R805 1-216-295-91 SHORT 0
R807 1-216-295-91 SHORT 0
R813 1-216-295-91 SHORT 0
R820 1-216-073-00 RES,CHIP 10K 5% 1/10W
R821 1-216-083-00 RES,CHIP 27K 5% 1/10W
R822 1-216-025-91 RES,CHIP 100 5% 1/10W
R824 1-216-295-91 SHORT 0
R825 1-216-295-91 SHORT 0
R827 1-216-295-91 SHORT 0
R828 1-216-025-91 RES,CHIP 100 5% 1/10W
R829 1-216-025-91 RES,CHIP 100 5% 1/10W
R830 1-216-295-91 SHORT 0
R831 1-216-295-91 SHORT 0
R832 1-208-790-11 RES,CHIP 2.2K 0.50% 1/10W
R835 1-216-295-91 SHORT 0
R839 1-216-655-11 RES,CHIP 1.5K 0.50% 1/10W
R841 1-216-025-91 RES,CHIP 100 5% 1/10W
R842 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R843 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R844 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R845 1-216-049-91 RES,CHIP 1K 5% 1/10W
R846 1-216-049-91 RES,CHIP 1K 5% 1/10W
R847 1-216-049-91 RES,CHIP 1K 5% 1/10W
R848 1-216-049-91 RES,CHIP 1K 5% 1/10W
R849 1-216-049-91 RES,CHIP 1K 5% 1/10W
R850 1-216-105-91 RES,CHIP 220K 5% 1/10W
R851 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R853 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R857 1-216-081-00 RES,CHIP 22K 5% 1/10W
R858 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R861 1-216-049-91 RES,CHIP 1K 5% 1/10W
R862 1-260-095-11 CARBON 470 5% 1/2W
R863 1-216-049-91 RES,CHIP 1K 5% 1/10W
R864 1-216-041-00 RES,CHIP 470 5% 1/10W
R866 1-215-880-00 METAL OXIDE 10 5% 2W F
R871 1-216-037-00 RES,CHIP 330 5% 1/10W
R879 1-216-073-00 RES,CHIP 10K 5% 1/10W
R880 1-216-041-00 RES,CHIP 470 5% 1/10W
R882 1-216-049-91 RES,CHIP 1K 5% 1/10W
R884 1-216-025-91 RES,CHIP 100 5% 1/10W
R888 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R889 1-216-073-00 RES,CHIP 10K 5% 1/10W
R890 1-216-081-00 RES,CHIP 22K 5% 1/10W
R894 1-216-073-00 RES,CHIP 10K 5% 1/10W
R895 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R896 1-216-073-00 RES,CHIP 10K 5% 1/10W
R897 1-216-073-00 RES,CHIP 10K 5% 1/10W
R898 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
<CRYSTAL>
X801 1-578-774-11 VIBRATOR, CRYSTAL
*************************************************************
V1
