Sony KV-EF34M31 - Page 86

REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
The components identified by
shading and mark ! are criti-
cal for safety.
Replace only with part number
specified.
Les composants identifies par
une trame et une marque !
sont critiques pour la securite.
Ne les remplacer que par une
piece portant le numero specifie.
-------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------------------------------------------
-------------------
KV-EF34M31/EF34M61/EF34M80/EF34M90/EF34M91
RM-951
– 132 –
*A-1343-584-A D2 BOARD, COMPLETE
***********************
<CAPACITOR>
C2801 1-130-479-00 MYLAR 0.0047MF 5% 50V
C2803 1-136-357-11 FILM 680PF 5% 50V
C2805 1-104-664-11 ELECT 47MF 20% 25V
C2806 1-136-559-11 MYLAR 0.0047MF 10% 400V
C2809 1-126-964-11 ELECT 10MF 20% 50V
C2810 1-102-228-00 CERAMIC 470PF 10% 500V
C2811 1-107-938-11 ELECT 0.47MF 20% 160V
C2813 1-107-636-11 ELECT 10MF 20% 160V
C2814 1-126-964-11 ELECT 10MF 20% 50V
C2817 1-102-244-00 CERAMIC 220PF 10% 500V
C2818 1-129-928-00 FILM 0.0027MF 5% 630V
C2819 1-104-664-11 ELECT 47MF 20% 25V
C2820 1-107-714-11 ELECT 10MF 20% 16V
C2821 1-130-469-00 MYLAR 680PF 5% 50V
C2822 1-106-375-12 MYLAR 0.022MF 10% 250V
C2824 1-104-664-11 ELECT 47MF 20% 25V
C2825 1-136-601-11 FILM 0.01MF 5% 630V
C2826 1-137-194-81 FILM 0.47MF 5% 50V
C2828 1-107-714-11 ELECT 10MF 20% 16V
C2829 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C2830 1-110-205-11 FILM 0.0068MF 5% 50V
C2832 1-126-960-11 ELECT 1MF 20% 50V
C2833 1-137-366-11 FILM 0.0022MF 5% 50V
C2834 1-106-220-00 MYLAR 0.1MF 10% 100V
C2835 1-216-295-91 SHORT 0
C2837 1-102-129-00 CERAMIC 0.01MF 10% 50V
C2840 1-110-174-71 MYLAR 0.082MF 5% 100V
C2841 1-136-177-00 FILM 1MF 5% 50V
C2842 1-130-477-00 MYLAR 0.0033MF 5% 50V
C2843 1-107-714-11 ELECT 10MF 20% 16V
<CONNECTOR>
CN2821 * 1-564-506-11 PLUG, CONNECTOR 3P
CN2822 * 1-564-510-11 PLUG, CONNECTOR 7P
CN2823 1-695-915-11 TAB (CONTACT)
<DIODE>
D2801 8-719-404-49 DIODE MA111
D2803 8-719-063-73 DIODE D1NL20U-TR
D2804 8-719-063-73 DIODE D1NL20U-TR
D2806 8-719-302-43 DIODE EL1Z
D2813 8-719-404-49 DIODE MA111
D2814 8-719-210-21 DIODE 11EQS04
D2815 8-719-911-19 DIODE 1SS119-25
D2816 8-719-911-19 DIODE 1SS119-25
<IC>
IC2801 8-759-700-07 IC NJM2903M
IC2803 8-759-701-59 IC NJM78M09FA
IC2805 8-759-998-98 IC LM358D
IC2806 8-759-700-07 IC NJM2903M
<CHIP CONDUCTOR>
JR2803 1-216-295-91 SHORT 0
JR2804 1-216-295-91 SHORT 0
JR2805 1-216-295-91 SHORT 0
JR2815 1-216-295-91 SHORT 0
<COIL>
L2801 1-406-677-11 INDUCTOR 10mH
L2802 1-459-111-00 INDUCTOR 10mH
L2803 1-414-502-21 INDUCTOR 33mH
L2806 1-406-677-11 INDUCTOR 10mH
<TRANSISTOR>
Q2802 8-729-216-22 TRANSISTOR 2SA1162-G
Q2805 8-729-216-22 TRANSISTOR 2SA1162-G
Q2806 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2807 8-729-043-95 TRANSISTOR 2SC3840(3)
Q2811 8-729-931-45 TRANSISTOR IRF614
Q2813 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2821 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2822 8-729-216-22 TRANSISTOR 2SA1162-G
Q2823 8-729-017-06 TRANSISTOR 2SC4793
Q2824 8-729-140-97 TRANSISTOR 2SB734-34
<RESISTOR>
R2801 1-216-057-91 RES,CHIP 2.2K 5% 1/10W
R2803 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2804 1-216-041-00 RES,CHIP 470 5% 1/10W
R2806 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2809 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2812 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2813 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2816 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2820 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2821 1-249-412-11 CARBON 390 5% 1/4W F
R2824 1-249-393-11 CARBON 10 5% 1/4W F
R2825 1-216-037-00 RES,CHIP 330 5% 1/10W
R2827 1-216-041-00 RES,CHIP 470 5% 1/10W
R2830 1-215-899-11 METAL OXIDE 15K 5% 2W F
R2831 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
R2833 1-216-460-00 METAL OXIDE 3.9K 5% 2W F
R2834 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
R2837 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R2838 1-216-675-00 RES,CHIP 10K 5% 1/10W
R2839 1-216-081-00 RES,CHIP 22K 5% 1/10W
R2840 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2843 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2844 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2846 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2847 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2857 1-216-671-00 RES,CHIP 6.8K 5% 1/10W
R2858 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R2859 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2860 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R2861 1-216-107-00 RES,CHIP 270K 5% 1/10W
R2862 1-216-107-00 RES,CHIP 270K 5% 1/10W
R2866 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2867 1-216-081-00 RES,CHIP 22K 5% 1/10W
R2869 1-216-113-00 RES,CHIP 470K 5% 1/10W
R2871 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2872 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2874 1-216-085-00 RES,CHIP 33K 5% 1/10W
R2877 1-216-421-11 METAL OXIDE 12 5% 1W F
R2878 1-216-081-00 RES,CHIP 22K 5% 1/10W
R2879 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2880 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2882 1-216-657-00 RES,CHIP 1.8K 5% 1/10W
R2883 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R2884 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R2885 1-216-689-11 RES,CHIP 39K 5% 1/10W
R2886 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R2887 1-216-651-91 RES,CHIP 1K 5% 1/10W
R2888 1-216-049-91 RES,CHIP 1K 5% 1/10W
D2
