Sony LDM-3210 - DISASSEMBLY PROCEDURES; DISPLAY UNIT-1 (LDM-3210) Disassembly

KDL32XBR950/KDL42XBR950 (UC) 1-1
SECTION 1
DISASSEMBLY
1-1. DISPLAY UNIT-1 (LDM-3210)
1-1-1. STAND ASSY AND REAR COVER REMOVAL
1-1-2. DES AND K BOARDS REMOVAL
2
4
1
Five screws
(+BVTP 4X16)
Four screws
(+PSW 5X14)
3
Stand assy
Rear cover
3
2
4
5
6
7
9
0
qa
1
8
Twenty five screws
(+BVTT 3X6)
Four screws
(+PSW 5X10)
Two screws
(+BVTT 4X10)
8
Two screws
(+BVTT 4X10)
Two screws
(M2.6 S HEAD EG)
Two screws (HEX)
Five screws
(+BVTT 3X6)
Five screws
(+BVTT 3X6)
DES board
Shield case,S32 (center)
K board
Main arm S32 (R)
