Sony MAV-777 User Manual

Chapter 3 Operating Modes 3-61 (E)
Operations in the Warning dialog box
• A buzzer sounds when the Warning dialog box is displayed and menu item
3007 Buzzer On Error is set to On in CP Setup mode.
• Press the B7 (OK) key to stop the buzzer or close the Warning dialog box.
3-7-8 Alias Sheet Dialog Box
In Dual Play mode, press the B2 (New Alias) or B3 (Modify Alias) key to
open the Alias Sheet dialog box. Use the Alias Sheet dialog box to set the IN
points, OUT points, duration, or ports used for two different materials as a
single alias.
Items displayed in the Alias Sheet dialog box
Number
1
2
3
4
5
6
7
8
Name
Alias name (Alias
Name)
Loop playback
(Loop)
Foreground
material name
(FG Material)
Background
material name
(BG Material)
Foreground
information
Forground port
(Port)
Background
information
Background port
(Port)
Information displayed
Displays the alias name of the alias currently the subject
of operation.
Specifies whether or not loop playback is enabled for
the alias currently the subject of operation.
Displays the material name of the material specified as
the foreground.
Displays the material name of the material specified as
the background.
Displays the IN point, OUT point, and duration of the
material specified as the foreground.
Displays the port that is the subject of operation for the
material specified as the foreground.
Displays the IN point, OUT point, and duration of the
material specified as the background.
Displays the port that is the subject of operation for the
material specified as the background.
7 8
5
6
4
3
1
2
