Parts Identification
The items are arranged in alphabetical order.
Refer to the pages indicated in parentheses ( ) for details.
Main unit
AMS qf (8) (10) (12) (13) (24)
CLEAR qd (18) (24)
Display qg (8) (17)
INPUT qj (8)
LEVEL/DISPLAY/CHAR 2 (8)
(12) (24)
MD insertion slot 5 (16)
MD/LP indicator 3 (10) (17)
MENU/NO 7 (10) (18) (20)
PHONE LEVEL w; (17)
PHONES jack ql (17)
PLAY MODE 4 (16)
REC MODE qk (9)
Remote sensor qh (7)
YES 8 (10) (18) (20)
?/1 (power)/STANDBYindicator
1 (8) (16)
Z (eject) 6 (8) (17)
NX (play/pause) 9 (8) (16)
x (stop) 0 (8) (16)
m (go back)/M (go forward)
qa (17) (18) (24)
z (recording) qs (8)
