HCD-EC719iP/EC919iP
9
2-3. POWER CORD (AC1), REAR PANEL BLOCK
5 connector
(XP16)
4 fan connector
(XP14)
7 claw
7 claw
9 rear panel block
8 Remove the rear panel block
in the direction of an arrow.
1 power cord connector
(CN501)
3 power cord
(AC1)
– Rear view –
7 claw
7 claw
(EC919iP)
OK
NG
Note 2:
When installing the rear
panel block, check that
jacks are properly secured.
Jacks are fitted to
the surface.
Jacks has been
depressed.
6 screw
(silver 3 u 8)
6 screw
(silver 3 u 8)
6 screw
(silver 3 u 8)
2
Power cord setting
– Rear view –
Note 1:
When installing the power cord (AC1),
check the direction of connector.
To Next Page
