Sony MHC-EC619iP Service Manual

HCD-EC719iP/EC919iP
7
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-2. SIDE COVER,
TOP COVER BLOCK
(Page 8)
SET
2-3. POWER CORD (AC1),
REAR PANEL BLOCK
(Page 9)
2-4. CD DOOR
(Page 10)
2-6. MAIN BOARD BLOCK
(Page 11)
2-8. POWER BOARD
(Page 12)
2-7. MAIN BOARD
(Page 11)
2-10. USB BOARD
(Page 14)
2-11. LOADER WITH FFC (TDL-5) (CDM1)
(Page 14)
2-9. FRONT BOARD
(Page 13)
2-5. FRONT PANEL BLOCK
(Page 10)

Sony MHC-EC619iP Specifications

General

Karaoke	No
Impedance	8 Ω
Bass reflex	-
Speaker type	2-way
RMS rated power	120 W
Woofer diameter	130 mm
Tweeter diameter	40 mm
Number of speakers	2
Type	Home audio mini system
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Recording on	CD, USB
Playback modes	Normal, Repeat all, Repeat one, Shuffle
Disc types supported	CD, CD-R, CD-RW
Audio formats supported	MP3, WMA
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	20
Display type	VFD
Display digits	8 digits
Backlight color	White
Apple docking compatibility	iPhone 5, iPhone 5c, iPhone 5s, iPod Touch 5
On Screen Display (OSD) languages	English
Equalizer modes	Hip hop, Jazz, Pop, Rock
Battery type	AA
Power source	AC/Battery
Power consumption (standby)	0.5 W
Power consumption (typical)	55 W

Weight and Dimensions

Net weight	2400 g
Main unit dimensions (WxDxH)	193 x 300 x 260 mm
