MHC-RV555D/RV333D/RV222D.GB.4-136-609-11(1)
13
GB
Guide to parts and controls
REC TO TAPE button (page 64)
Press to record on a tape.
(stop) button (page 34, 60, 62,
63, 80)
Press to stop playback.
(fast forward) button (page
34, 62)
Press to nd a point in a track, le,
chapter or video le.
button (page 34)
Press to watch the slow-motion play.
TUNING + button (page 60)
Press to tune in the desired station.
(Models with Karaoke function
only)
MIC jack (page 64, 67)
Connect a microphone.
MIC LEVEL control (page 67)
Turn to adjust the microphone volume.
PHONES jack
Connect the headphones.
VIDEO INPUT VIDEO jack
VIDEO INPUT AUDIO L/R jack
See page 80.
(MHC-RV333D only)
SUBWOOFER button (page 65)
Press to adjust the sound level of the
subwoofer.
(rewind) button (page 34,
62)
Press to nd a point in a track, le,
chapter or video le.
button (page 34)
Press to watch the slow-motion play.
TUNING button (page 60)
Press to tune in the desired station.
Continued
To Next Page
