MHC-V3/V4D
38
USB board
TUNER board
ARAGON board
PANEL board
MIC board
DAMP board
SMPS board
BLUETOOTH module
SPEAKER LED board
IR board
MS-476 board
RC-S801/A5 (WW)
(V4D)
SECTION 6
DIAGRAMS
• Circuit Boards Location
Ver. 1.5
