Sony Model MHC-WZ8D User Manual

32
GB
Note
When connecting a sub woofer, make sure to set the
SUBWOOFER setting to “YES”. If set to “NONE”, no
sound is output from the sub woofer.
Specifying the surround speaker
position and height (except for
European, Russian and Latin
American models)
If you select anything other than “NONE” in
“SURROUND”, specify the position and height
of the surround speakers.
x DISTANCE
The default distance setting for the speakers in
relation to the listening position is shown below.
Be sure to change the value in the Setup Display
when you move the speakers.
Notes
• If each of the front and surround speakers are not
placed at an equal distance from your listening
position, set the distance of the closest speaker.
• Do not place the surround speakers farther away from
your listening position than the front speakers.
BEHIND (LOW)
Select this if the surround
speakers are located in section
B and D.
BEHIND (HIGH) Select this if the surround
speakers are located in section
B and C.
SIDE (LOW) Select this if the surround
speakers are located in section
A and D.
SIDE (HIGH) Select this if the surround
speakers are located in section
A and C.
90
20
45
60
30
Position diagram
Height diagram
FRONT
3.0 m
Front speaker distance from the
listening position can be set in
0.2 meter increments from 1.0 to
7.0 meters.
CENTER
3.0 m
Center speaker distance can be
moved up to 1.6 meters closer to the
listening position, from the front
speakers in 0.2 meter increments.
SURROUND
3.0 m
Surround speaker distance can be
moved up to 4.6 meters closer to the
listening position, from the front
speakers, in 0.2 meter increments.
3m 3m
3m
3m 3m
