Sony MP-CL1 User Manual

MP-CL1 3-MP0-107-01

Jog lever (−/ENTER/+)
Press the jog lever while at the ENTER position to display the menu. Slide it to +
or − to move to next or previous menu item, and then press while at the ENTER
position to select the highlighted item.

Speaker

Built-in Wi-Fi antenna

HDMI/MHL IN jack

AUDIO OUT jack
Connect headphones or speakers to this jack.

USB OUT jack (for power supply)
Connect another device to this jack to charge it. The
lamp lights up in green
while charging the device.

Ventilation holes

(charge) lamp

 (power) lamp

Lens
Laser radiates from this aperture.

Sony MP-CL1 Specifications

General

Display Technology	Laser Beam Scanning
Resolution	1920 x 720
Brightness	32 lumens
Contrast Ratio	80, 000:1
Battery Life	up to 2 hours
Aspect Ratio	16:9
Built-in Speaker	Yes
Projection Size	up to 120 inches
Connectivity	HDMI, MHL, Wi-Fi
Weight	210 g
Dimensions	Approx. 149.5 mm x 77.0 mm x 13.0 mm (5 7/8 inches x 3 1/8 inches x 1/2 inches)
