– 84 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
• Abbreviation
CND : Canadian CET : East European, Russian
IT : Italian AUS : Australian
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
* A-3306-627-A AUDIO BOARD, COMPLETE (D305L)
* A-3306-835-A AUDIO BOARD, COMPLETE (D305)
**********************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C101 1-162-294-31 CERAMIC 0.001uF 10% 50V
C102 1-126-967-11 ELECT 47uF 20% 10V
C103 1-161-020-11 CERAMIC 0.039uF 10% 16V
C104 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C105 1-162-215-31 CERAMIC 47PF 5% 50V
C106 1-126-959-11 ELECT 0.47uF 20% 50V
C108 1-126-959-11 ELECT 0.47uF 20% 50V
C112 1-126-964-11 ELECT 10uF 20% 50V
C141 1-126-964-11 ELECT 10uF 20% 50V
C142 1-162-294-31 CERAMIC 0.001uF 10% 50V
C143 1-126-964-11 ELECT 10uF 20% 50V
C144 1-162-849-11 CERAMIC 0.068uF 10% 16V
C145 1-162-849-11 CERAMIC 0.068uF 10% 16V
C146 1-162-839-11 CERAMIC 0.01uF 10% 16V
C147 1-126-960-11 ELECT 1uF 20% 50V
C152 1-162-294-31 CERAMIC 0.001uF 10% 50V
C153 1-126-967-11 ELECT 47uF 20% 10V
C155 1-107-909-11 ELECT 47uF 20% 10V
C156 1-162-282-31 CERAMIC 100PF 10% 50V
C201 1-162-294-31 CERAMIC 0.001uF 10% 50V
C202 1-126-967-11 ELECT 47uF 20% 10V
C203 1-161-020-11 CERAMIC 0.039uF 10% 16V
C204 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C205 1-162-215-31 CERAMIC 47PF 5% 50V
C206 1-126-959-11 ELECT 0.47uF 20% 50V
C208 1-126-959-11 ELECT 0.47uF 20% 50V
C210 1-162-282-31 CERAMIC 100PF 10% 50V
(D305L)
C212 1-126-964-11 ELECT 10uF 20% 50V
C241 1-126-964-11 ELECT 10uF 20% 50V
C242 1-162-294-31 CERAMIC 0.001uF 10% 50V
C243 1-126-964-11 ELECT 10uF 20% 50V
C244 1-162-849-11 CERAMIC 0.068uF 10% 16V
C245 1-162-849-11 CERAMIC 0.068uF 10% 16V
C246 1-162-839-11 CERAMIC 0.01uF 10% 16V
C247 1-126-960-11 ELECT 1uF 20% 50V
C252 1-162-294-31 CERAMIC 0.001uF 10% 50V
C253 1-126-967-11 ELECT 47uF 20% 10V
C255 1-107-909-11 ELECT 47uF 20% 10V
C256 1-162-282-31 CERAMIC 100PF 10% 50V
C301 1-126-933-11 ELECT 100uF 20% 10V
C302 1-126-925-11 ELECT 470uF 20% 10V
C303 1-126-963-11 ELECT 4.7uF 20% 50V
C304 1-126-933-11 ELECT 100uF 20% 10V
C307 1-161-494-00 CERAMIC 0.022uF 25V
C311 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C312 1-126-967-11 ELECT 47uF 20% 10V
C313 1-137-350-11 MYLAR 0.015uF 10% 100V
C314 1-162-294-31 CERAMIC 0.001uF 10% 50V
C315 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C316 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C324 1-126-961-11 ELECT 2.2uF 20% 50V
C325 1-126-961-11 ELECT 2.2uF 20% 50V
C326 1-126-963-11 ELECT 4.7uF 20% 50V
C327 1-126-967-11 ELECT 47uF 20% 10V
C328 1-126-959-11 ELECT 0.47uF 20% 50V
C329 1-137-189-11 FILM 0.18uF 5% 50V
C333 1-126-967-11 ELECT 47uF 20% 10V
C334 1-126-963-11 ELECT 4.7uF 20% 50V
C335 1-126-960-11 ELECT 1uF 20% 50V
C336 1-126-961-11 ELECT 2.2uF 20% 50V
C337 1-126-933-11 ELECT 100uF 20% 10V
C338 1-161-494-00 CERAMIC 0.022uF 25V
C339 1-161-494-00 CERAMIC 0.022uF 25V
C340 1-162-282-31 CERAMIC 100PF 10% 50V
(D305L)
C340 1-162-290-31 CERAMIC 470PF 10% 50V
(D305)
C341 1-162-282-31 CERAMIC 100PF 10% 50V
(D305L)
C341 1-162-290-31 CERAMIC 470PF 10% 50V
(D305)
C342 1-162-282-31 CERAMIC 100PF 10% 50V
(D305L)
C342 1-162-290-31 CERAMIC 470PF 10% 50V
(D305)
C344 1-162-282-31 CERAMIC 100PF 10% 50V
AUDIO
