– 94 –
C66 1-137-399-11 FILM 0.1uF 5% 50V
(D305L)
C69 1-161-494-00 CERAMIC 0.022uF 25V
(D305L)
C70 1-136-356-11 FILM 470PF 5% 63V
(D305L)
C72 1-162-282-31 CERAMIC 100PF 10% 50V
(D305L)
C73 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305L)
C74 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305L)
C75 1-162-281-31 CERAMIC 91PF 10% 50V
(D305L)
C76 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305L)
C84 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305L)
C88 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305L)
C89 1-162-294-31 CERAMIC 0.001uF 10% 50V
(D305: AUS)
C90 1-162-282-31 CERAMIC 100PF 10% 50V
(D305: US, CND, E)
C90 1-162-294-31 CERAMIC 0.001uF 10% 50V
(D305: AUS)
C91 1-162-282-31 CERAMIC 100PF 10% 50V
C92 1-162-282-31 CERAMIC 100PF 10% 50V
(D305: AUS)
C93 1-162-282-31 CERAMIC 100PF 10% 50V
(D305)
C93 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305L)
C94 1-162-282-31 CERAMIC 100PF 10% 50V
(D305)
C95 1-162-282-31 CERAMIC 100PF 10% 50V
(D305L)
C95 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305)
C96 1-162-294-31 CERAMIC 0.001uF 10% 50V
(D305L)
C96 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305)
C97 1-162-282-31 CERAMIC 100PF 10% 50V
(D305: AUS)
C99 1-162-294-31 CERAMIC 0.001uF 10% 50V
(D305L)
C99 1-162-306-11 CERAMIC 0.01uF 20% 16V
(D305: AUS)
< FILTER >
CF1 1-767-355-11 FILTER, CERAMIC (D305)
CF1 1-767-557-11 FILTER, CERAMIC (D305L)
CF2 1-767-355-11 FILTER, CERAMIC (D305)
CF2 1-767-557-11 FILTER, CERAMIC (D305L)
CF3 1-767-355-11 FILTER, CERAMIC (D305)
CF3 1-767-557-11 FILTER, CERAMIC (D305L)
CF4 1-767-096-11 VIBRATOR, CERAMIC
< ENCAPSULATED COMPONENT >
CFT1 1-233-885-11 ENCAPSULATED COMPONENT (D305)
CFT1 1-239-173-11 ENCAPSULATED COMPONENT (D305L)
< CONNECTOR >
CNP1 1-778-310-11 PLUG, CONNECTOR 2P (AM)
* CNP2 1-564-187-00 PIN, CONNECTOR (FM) (D305)
CNP2 1-779-535-11 CONNECTOR, COAXIAL (EXT ANT) (D305L)
CNP3 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
< TRIMMER >
CT1 1-141-410-11 CAP, ADJ 10PF (D305)
CT2 1-141-410-11 CAP, ADJ 10PF (D305)
CT4 1-141-410-11 CAP, ADJ 10PF (D305L)
CT5 1-141-439-21 CAP, ADJ (D305L)
< DIODE >
D1 8-719-991-33 DIODE 1SS133T-77 (D305)
D2 8-719-991-33 DIODE 1SS133T-77 (D305)
D3 8-719-918-45 DIODE KV1310 (D305)
D4 8-719-918-45 DIODE KV1310 (D305)
D5 8-719-050-69 DIODE KV1520N (D305)
D5 8-719-976-30 DIODE KV1560N (D305L)
D90 8-719-991-33 DIODE 1SS133T-77 (D305L)
D91 8-719-991-33 DIODE 1SS133T-77
D92 8-719-991-33 DIODE 1SS133T-77
D93 8-719-991-33 DIODE 1SS133T-77
D94 8-719-991-33 DIODE 1SS133T-77
D95 8-719-991-33 DIODE 1SS133T-77(D305L)
< FILTER >
FL1 1-236-711-21 FILTER, BAND PASS (D305)
< IC >
IC1 8-759-386-02 IC TA2008AN
IC2 8-759-290-61 IC BU2615S (D305L)
IC2 8-759-333-33 IC BU2614 (D305)
< COIL >
L1 1-416-226-11 COIL, FM RF (D305)
L2 1-416-225-11 COIL, FM OSC (D305)
L3 1-416-248-11 COIL, MW RF (D305L)
L3 1-416-251-11 COIL, MW ANT (D305)
L4 1-416-247-11 COIL (OSC) (D305L)
L4 1-416-250-11 COIL, AM OSC (D305)
L5 1-416-249-11 COIL, LW RF (D305L)
L6 1-412-514-11 INDUCTOR 220uH (D305L)
L40 1-410-527-11 INDUCTOR 100uH (D305)
L40 1-412-514-11 INDUCTOR 220uH (D305L)
L90 1-410-526-11 INDUCTOR 10uH (D305: AUS)
< TRANSISTOR >
Q1 8-729-905-50 TRANSISTOR DTC343TS (D305L)
Q1 8-729-922-66 TRANSISTOR 2SC2410SN (D305)
Q2 8-729-115-80 TRANSISTOR BA1A4P (D305)
Q2 8-729-905-50 TRANSISTOR DTC343TS (D305L)
Q3 8-729-115-80 TRANSISTOR BA1A4P (D305)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TUNER
