Sony PMC-D305 - HARDWARE AND ACCESSORIES

– 96 –
(D305)
R60 1-249-429-11 CARBON 10K 5% 1/4W
(D305L)
R61 1-249-425-11 CARBON 4.7K 5% 1/4W
(D305L)
R62 1-249-425-11 CARBON 4.7K 5% 1/4W
(D305L)
R63 1-249-441-11 CARBON 100K 5% 1/4W
(D305L)
R64 1-247-887-00 CARBON 220K 5% 1/4W
(D305L)
R64 1-249-441-11 CARBON 100K 5% 1/4W
(D305)
R65 1-247-807-31 CARBON 100 5% 1/4W
(D305)
R65 1-249-411-11 CARBON 330 5% 1/4W
(D305L)
R66 1-249-413-11 CARBON 470 5% 1/4W
(D305L)
R67 1-249-429-11 CARBON 10K 5% 1/4W
(D305L)
R70 1-249-425-11 CARBON 4.7K 5% 1/4W
(D305L)
R71 1-249-425-11 CARBON 4.7K 5% 1/4W
(D305L)
R72 1-249-425-11 CARBON 4.7K 5% 1/4W
(D305L)
R73 1-247-887-00 CARBON 220K 5% 1/4W
(D305L)
R74 1-249-416-11 CARBON 820 5% 1/4W
(D305L)
R76 1-249-441-11 CARBON 100K 5% 1/4W
(D305L)
R90 1-249-429-11 CARBON 10K 5% 1/4W
(D305: US, CND, E)
< ENCAPSULATED COMPONENT >
T1 1-233-306-31 ENCAPSULATED COMPONENT (D305L)
< TUNER UNIT >
* TU1 1-693-378-11 TUNER UNIT (D305L)
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
MISCELLANEOUS
**************
3 1-782-296-11 WIRE, PARALLEL (FFC) (27 CORE)
102 1-782-294-11 WIRE, PARALLEL (FFC) (9 CORE)
111 1-452-732-11 MAGNET
120 1-769-069-11 CABLE, FFC 16P
! 151 8-848-376-11 OPTICAL PICK-UP KSS-213B/S-RP
306 1-782-509-11 CORD, SPEAKER
308 X-3374-496-1 CORD ASSY
! 310 1-575-651-11 CORD, POWER (D305L: AEP, IT, CET)
! 310 1-575-653-11 CORD, POWER (D305: E)
! 310 1-696-847-11 CORD, POWER (D305: AUS)
! 310 1-751-520-11 CORD, POWER (D305L: UK)
! 310 1-769-743-11 CORD, POWER (D305: US, CND)
352 1-782-509-11 CORD, SPEAKER
HRPE1011-500-480-11 HEAD, MAGNETIC (REC/PB/ERASE)
M691 3-016-425-01 MOTOR ASSY (CARSTAN/REEL)
M701 X-2625-770-1 CHASSIS ASSY (MB) (RP), MOTOR (SPINDLE)
M702 X-2625-769-1 GEAR ASSY (MB), MOTOR (SLED)
PM691 1-454-806-11 SOLENOID, PLUNGER
S801 1-692-960-11 SWITCH, PUSH (1 KEY) (OPEN/CLOSE)
SP101 1-505-607-11 SPEAKER (8CM) (L-CH)
SP201 1-505-607-11 SPEAKER (8CM) (R-CH)
! T501 1-431-353-11 TRANSFORMER, POWER (D305: AUS/D305L)
! T501 1-431-354-11 TRANSFORMER, POWER (D305: US, CND, E)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-247-19 SCREW +KTP 3X10 TYPE2 NON-SLIT
#3 7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
#4 7-685-136-19 SCREW +P 2.6X12 TYPE2 NON-SLIT
#5 7-685-547-19 SCREW +BTP 3X10 TYPE2 N-S
#6 7-685-851-04 SCREW +BVTT 2X4 (S)
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-621-255-15 SCREW +P 2X3
#9 7-685-645-79 SCREW +P 3X6 TYPE2 NON-SLIT
#10 7-685-158-19 SCREW +P 4X6 TYPE2 NON-SLIT
#11 7-685-153-19 SCREW +P 3X30 TYPE2 NON-SLIT
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-501-594-11 ANTENNA (FM) (D305L)
1-501-843-11 ANTENNA, ROOP
1-558-271-11 CORD, CONNECTION
3-860-142-11 MANUAL, INSTRUCTION
(ENGLISH, GERMAN)(D305L: AEP, UK)
3-860-142-21 MANUAL, INSTRUCTION
(FRANCH, SPANISH) (D305L: AEP)
3-860-142-31 MANUAL, INSTRUCTION
(DUTCH, SWEDISH, PORTUGUESE)
(D305L: AEP)
3-860-142-41 MANUAL, INSTRUCTION
(ITALIAN) (D305L: AEP)
3-860-142-51 MANUAL, INSTRUCTION (ENGLISH) (D305)
3-860-142-61 MANUAL, INSTRUCTION (FRENCH)
(D305: CND)
3-860-142-71 MANUAL, INSTRUCTION (SPANISH) (D305: E)
3-860-142-81 MANUAL, INSTRUCTION
(POLISH, CZECH, HUNGARIAN) (D305: CET)
8-917-598-90 REMOTE COMMANDER RMT-C305A SET
(D305)
8-917-602-90 REMOCON, RMT-C305AD SET (D305L)
4-991-047-01 LID, BATTERY CASE (for RMT-C305)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
Sony Corporation
Personal A&V Products Company
PMC-D305/D305L
97G0587-1
Printed in Japan © 1997. 7
Published by Quality Engineering Dept.
(Shibaura)
9-923-212-11
TUNER
