Setting Up 27
GB
Setting Up
2 Connect the audio connecting cord (supplied) to
the SIGNAL OUTPUT jacks of the player and the
SIGNAL INPUT jacks of the left speaker.
Connect the white plugs to the L (left) jacks and
the red plugs to the R (right) jacks.
3 Connect the speaker cord of the right speaker to
the SPEAKER OUT terminals of the left speaker.
Connect the red wire to the (+) plus terminal, and
the black wire to the (–) minus terminal.
continued
To Next Page
