Sony PMW-EX1 - Camera Block Specifications

Specifications / Specifications
131
Appendixes
HQ mode: Approx. 50 min.
With one SBP-32
SP mode: Approx.140 min.
HQ mode: Approx. 100 min.
Continuous operation time
(Recording, EVF On, LCD monitor Off)
With the BP-U60
Approx. 4 hours
With the BP-U30
Approx. 2 hours
Mass
Camcorder: 2.4 kg (5 lb 5 oz)
With the supplied lens hood, eyecup,
BP-U30 battery pack and one SxS
memory card: 2.8 kg (6 lb 3 oz)
Dimensions
See page 133.
Supplied accessories
See page 9.
Lens
Focal length
5.8 mm to 81.2 mm
(equivalent to 31.4 mm to 439 mm on
35 mm lens)
Zoom
Servo/Manual selectable
Zoom ratio
14×
Maximum relative aperture
1:1.9
Iris
Auto/Manual selectable
F1.9 to F16 and C (close)
Focus
Auto/Manual selectable
Ranges:
800 mm to
∞ (Macro OFF)
50 mm to
∞ (Macro ON, Wide)
735 mm to
∞ (Macro ON, Tele)
Picture stabilizing function
SteadyShot ON/OFF possible, shift-lens
system
Filter thread
M77 mm, pitch 0.75 mm
Macro
ON/OFF switchable
Camera
Pickup device
1
/
2
-inch type, CMOS image sensor
Effective picture elements:
1920 (H) × 1080 (V)
Format
3-chip RGB
Optical system
F1.6 prism system
Built-in filters
ND filters
OFF: Clear
1:
1
/
8
ND
2:
1
/
64
ND
Sensitivity
F10 (Typical) (With 1080/60i, 89.9%
reflection, 2000 lx)
Minimum illumination
0.14 lx (F1.9, +18 dB, 64-frame
accumulation)
Video S/N
54 dB (Y) (Typical)
Horizontal resolution
1000TV lines or more (with HQ 1080,
HD SDI output)
Gain
–3, 0, 3, 6, 9, 12, 18 dB, AGC
Shutter speed
1
/
32
to
1
/
2000
sec.
Slow shutter
2 to 8 frames
EX Slow Shutter: 16, 32, 64 frames
Camera Block
