4-7-2. Performance Check
Press “ESC” key, then “A.MON” key.
This is a reading test across all sectors of the HDD.
Data recorded on the HDD will not be erased, because no writing operation is performed.
Time required for testing: Approx. 45 min/160 G
75 min/250 G
130 to 150 min/500 G
When “Performance Check” finishes completely without error, reset “ATA/ATAPI History Error” with the Clear key.
0:Factory Check start 0 0 000000
Power On
FL display specification
HDD factory Check HDD performance Check
aNormal display aError display
1:Power ON Test
2:
Random Write/Read/Compare Test
3:ID Sequential Read Verify Test
4:
OD Sequential Read Verify Test
5:Format
7:Power ON Test
8:Power OFF Test
9:Power ON Test
a:Power OFF Test
b:Complete
6:Power OFF Test
6 0 000000
7 0 000000
8 0 000000
9 0 000000
A
0 000000
B
COMPLETE
1 0 000000 81 0 00000
HDD ERR 01
HDD ERR 02
aError display
HDD ERR 81
HDD ERR 82
HDD ERR 03
HDD ERR 04
HDD ERR 05
HDD ERR 07
HDD ERR 09
2 0 000000
3
**
*****
H M S
80 0 00000
aNormal display
83 0 00000
H M S
8 4 COMPLETE
82
**
*****
H M S
4
**
*****
H M S
5 FM
*****
H M S
80:Performance Check start
81:Power ON Test
82:
all Sequential Read Verify Test
83:Power OFF Test
84:Complete
Power off
Power On15s
Power off
Power On
15s
15s
20s
20s
15s
Power off
Power On
Power off
Fig 1. FL Display Flow
* The logo for “Factory Check” and “Performance Check” is recorded in “ATA/ATAPI History Error”.
