— 8 —
Note: Write down the HDD information on the HDD
return sheet before replacing the HDD.
Note the information on pages 6-6, 6-7, 6-9,
and 6-10 of Chapter 6, “SERVICE MODE”.
For information about replacing the HDD, see
page 2-5 of Chapter 2, “DISASSEMBLY”.
After replacing the HDD, perform
“Factory Check” on “SERVICE NOTE”, page 10.
When performing “Factory Check”, the data
saved to the HDD by the customer is erased.
Obtain customer consent before performing
“Factory Check”.
E01
END
Is not “#” displayed?
Reconnect the SATA
cable. Does the problem
still occur?
Replace the SATA cable.
Does the problem
still occur?
Replace the HDD with a new
one and perform Factory Check.
YES
Is the HDD free from
abnormal noises?
YES
YES
YES
Does the problem
still occur?
There may be a problem with the Engine.
Therefore, put the original HDD back in the unit.
Then, follow the procedure to replace the Engine.
After replacing the Engine, perform “Setting the Model Name”
on “Service Note”, page 6.
YES
Does the problem
still occur?
Another defect
has occurred.
YES
Unauthorized HDD
Replace the SATA Cable
NO
NO
NO
NO
NO
Final check
NO
Replace the HDD
Note: Performing “Final Check” will not erase the HDD data.
*
Refer to “Note”.
*
Refer to “Note”.
Note: Write down the HDD information on the HDD
return sheet before replacing the Engine.
For information about replacing the Engine,
see page 2-4 of Chapter 2, “DISASSEMBLY”.
When performing “Factory Check”, the data
saved to the HDD by the customer is erased.
Obtain customer consent before performing
“Factory Check”.
4-3. Display [E01] on FLD with unrecognized HDD
