6-4
Check AVIC1
(Pin # 109, 110)
Check AIC4 (Pin # 1, 7)
Check peripheral parts of JK801
Check VCC of AVIC1 and peripheral
parts of Clock oscillation
(IC105 Pin # 1, 2, 14)
No
No
Check VCC and peripheral parts of AIC4.
Check applicatin of JACK 1
Yes
Yes
No Analog Audio Output
Check Audio input signal
1) Line 1 Audio input : AVIC1 Pin # 122, 123
2) Line 2 Audio input : AVIC1 Pin # 125, 126
To Next Page
