Sony RDR-GXD455 - Page 68

6-8
Check VC7, VC8
No
Check VCC of IC101 and peripheral
parts of Clock oscillation
(IC105 Pin # 1, 2, 14)
No
Yes
Yes
S-Video output error
Check VIC1
(Pin # 6, 8, 28, 31)
Check VCC and peripheral parts of
VIC 1
Check peripheral parts of SJACK
