7-5E
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< REGISTOR >
R1S13 1-245-575-11 R-METAL OXIDE
< SWITCH >
SW1 9-885-111-48 SWITCH TACT (POWER)
SW2 9-885-111-48 SWITCH TACT (ONE-TOUCH DUBBING)
< THERMISTOR >
0 R1S04 9-885-101-36 THERMISTOR-NTC
< TRANSFORMER >
0 PT01 9-885-102-62 TRANS SWITCHING EER3534
< TRANSISTOR >
Q1P103 9-885-070-38 FET FQP33N10
Q1PS01 9-885-070-32 TRANSISTOR KSC945
Q1PS02 9-885-070-33 TRANSISTOR KTC3203-Y
Q1PS03 9-885-070-36 TRANSISTOR KSR2001
Q1S01 9-885-036-95 FET
< VARISTOR >
VA1S01 9-885-070-65 VARISTOR
VA1S02 9-885-070-65 VARISTOR
* VA1S03 9-885-108-15 VARISTOR
< VIBRATOR >
XT601 9-885-070-67 CRYSTAL-UNIT (14.31818MHz)
FUNCTION TIMER BOARD
*********************
(This FUNCTION TIMER BOARD is included in
FRONT MAIN BOARD.)
< DIODE >
D701 9-885-111-32 DIODE 1N4148
D702 9-885-111-32 DIODE 1N4148
D703 9-885-111-32 DIODE 1N4148
D704 9-885-111-32 DIODE 1N4148
D705 9-885-111-32 DIODE 1N4148
D706 9-885-111-32 DIODE 1N4148
D707 9-885-111-32 DIODE 1N4148
< VFD DISPLAY >
DT701 9-885-090-97 VFD DISPLAY
< IC >
IC701 9-885-070-48 IC PT6315 (VFD)
< LED >
LD701 9-885-079-26 LED INVERTER, BLUE (HDMI)
< REMOCON MODULE >
RM701 9-885-069-95 MODULE REMOCON TSOP2240RF1
< SWITCH >
SW702 9-885-069-77 SWITCH-TACT DC12V (CH-DWN)
SW703 9-885-069-77 SWITCH-TACT DC12V (PAUSE)
SW704 9-885-069-77 SWITCH-TACT DC12V (CH-UP)
SW707 9-885-069-77 SWITCH-TACT DC12V (PLAY)
SW712 9-885-069-77 SWITCH-TACT DC12V (REC)
SW713 9-885-069-77 SWITCH-TACT DC12V (FF)
SW714 9-885-069-77 SWITCH-TACT DC12V (OPEN/CLOSE)
SW715 9-885-069-77 SWITCH-TACT DC12V (REW)
SW716 9-885-069-77 SWITCH-TACT DC12V (STOP)
MISCELLANEOUS
*************
6 9-885-102-43 CABLE-FLAT;30V, 80C, 360MM, 40P
0 8 1-824-674-11 POWER CORD EP2 SPT-2
11 9-885-090-91 FAN-DC
ACCESSORIES
************
3-096-488-11 MANUAL, INSTRUCTION (ENGLISH)
FRONT MAIN FUNCTION TIMER MAIN
The components identified by mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
