8-4
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
DVD MAIN FUNCTION TIMER VCR FRONT MAIN
QS03 9-885-070-30 TRANSISTOR KSC1623-L
QS04 9-885-070-30 TRANSISTOR KSC1623-L
< VIBRATOR >
AVXT01 9-885-070-70 CRYSTAL-SMD (24.576MHz)
MXTAL019-885-067-37 CRYSTAL (27MHz)
X1301 9-885-070-70 CRYSTAL-SMD (24.576MHz)
FUNCTION TIMER BOARD
*********************
< DIODE >
D701 9-885-111-32 DIODE SWITCHING 1N4148
D702 9-885-111-32 DIODE SWITCHING 1N4148
D703 9-885-111-32 DIODE SWITCHING 1N4148
D704 9-885-111-32 DIODE SWITCHING 1N4148
D705 9-885-111-32 DIODE SWITCHING 1N4148
D706 9-885-111-32 DIODE SWITCHING 1N4148
D707 9-885-111-32 DIODE SWITCHING 1N4148
< MODULE >
RM701 9-885-069-95 MODULE REMOCON TSOP2240RF1
< SWITCH >
SW702 9-885-069-77 SWITCH-TACT DC12V (CH-DWN)
SW703 9-885-069-77 SWITCH-TACT DC12V (PAUSE)
SW704 9-885-069-77 SWITCH-TACT DC12V (CH-UP)
SW707 9-885-069-77 SWITCH-TACT DC12V (PLAY)
SW712 9-885-069-77 SWITCH-TACT DC12V (REC)
SW713 9-885-069-77 SWITCH-TACT DC12V (FF)
SW714 9-885-069-77 SWITCH-TACT DC12V (OPEN/CLOSE)
SW715 9-885-069-77 SWITCH-TACT DC12V (REW)
SW716 9-885-069-77 SWITCH-TACT DC12V (STOP)
< VFD DISPLAY >
DT701 9-885-090-97 VFD DISPLAY
< IC >
IC701 9-885-070-48 IC PT6315 (VFD)
< LED >
LD701 9-885-079-26 LED (HDMI)
VCR FRONT MAIN BOARD
*********************
< CAPACITOR >
0 C1S02 1-100-358-11 CONDENSER CERAMIC DISC 100PF
0 C1S03 1-100-358-11 CONDENSER CERAMIC DISC 100PF
0 C1S04 9-885-079-30 CONDENSER 47nF
0 C1S05 9-885-079-30 CONDENSER 47nF
C1S07 1-165-990-11 CONDENSER 100PF
C1S08 1-165-574-11 CONDENSER FILM 10000PF
C1S12 1-165-574-11 CONDENSER FILM 10000PF
C1S39 1-165-999-11 CONDENSER FILM 0.1UF
< CONNECTOR >
CON1 9-885-102-57 HEADER-BOARD TO CABLE
< COIL/FERRITE BEAD/INDUCTOR >
BD1P01 1-400-086-11 FERRITE CORE
BD1S01 1-400-085-11 INDUCTOR 70uH
L02 1-424-828-11 COIL CHOKE 10uH
L03 1-424-828-11 COIL CHOKE 10uH
L04 1-424-828-11 COIL CHOKE 10uH
L601 1-400-082-11 INDUCTOR RA 100uH
0 L1S01 1-424-831-11 LINE FILTER 20mH
0 L1S02 1-424-830-11 LINE FILTER 30mH
L1S30 9-885-070-00 COIL CHOKE DR CHOKE (8*6)
L1S31 9-885-070-00 COIL CHOKE DR CHOKE (8*6)
L1S32 1-424-828-11 COIL CHOKE 10uH
LT01 1-400-074-11 INDUCTOR 100uH
RD701 9-885-083-84 BEAD-SMD 47ohm
RD702 9-885-083-84 BEAD-SMD 47ohm
RD703 9-885-083-84 BEAD-SMD 47ohm
RD704 9-885-083-84 BEAD-SMD 47ohm
RFR1 9-885-083-84 BEAD-SMD 47ohm
RFR2 9-885-083-84 BEAD-SMD 47ohm
RFR3 1-400-316-11 CORE-FERRITE BEAD 220ohm
RFR4 9-885-083-84 BEAD-SMD 47ohm
RFR5 9-885-083-84 BEAD-SMD 47ohm
RFR6 9-885-083-84 BEAD-SMD 47ohm
RFR7 1-400-316-11 CORE-FERRITE BEAD 220ohm
< DIODE >
BD01 1-804-413-11 DIODE IT5
BD02 1-804-413-11 DIODE IT5
BD03 1-804-413-11 DIODE IT5
BD04 1-804-413-11 DIODE IT5
D604 9-885-111-46 DIODE 1N5819
D605 9-885-111-32 DIODE 1N4148
D606 9-885-111-46 DIODE 1N5819
D1S05 9-885-070-13 DIODE UF4007
D1S06 9-885-111-32 DIODE 1N4148
D1S07 9-885-070-16 DIODE F1T4
D1S30 9-885-111-44 DIODE SHK75-11
D1S32 9-885-111-44 DIODE SHK75-11
D1S33 9-885-111-44 DIODE SHK75-11
D1S34 9-885-070-16 DIODE F1T4
* D1S35 9-885-108-57 DIODE SF34
D1S37 9-885-070-16 DIODE F1T4
* D1S38 9-885-102-60 DIODE 1N5408
D1S40 9-885-070-16 DIODE F1T4
D1S30A 9-885-111-44 DIODE SHK75-11
D1S33A 9-885-111-44 DIODE SHK75-11
* VZ01 9-885-102-51 DIODE CDS3C30GTH
* VZ02 9-885-102-51 DIODE CDS3C30GTH
* VZ03 9-885-102-51 DIODE CDS3C30GTH
* VZ04 9-885-102-51 DIODE CDS3C30GTH
* VZ05 9-885-102-51 DIODE CDS3C30GTH
* VZ06 9-885-102-51 DIODE CDS3C30GTH
* VZ07 9-885-102-51 DIODE CDS3C30GTH
ZD401 9-885-070-19 DIODE UZP33B
ZD1P05 9-885-070-18 DIODE UZP27B
ZD1P06 9-885-070-17 DIODE UZ5.6BM
ZD1S01 9-885-070-25 DIODE MTZJ4
ZD1S02 9-885-036-94 DIODE MTZJ20B
The components identified by mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number specified.
