NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• Not all of the parts are listed.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• CAPACITORS:
uF: µF
• COILS
uH: µH
8-2 ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
When indicating parts by reference number,
please include the board name.
DVD MAIN
9-885-112-13 DVD MAIN BOARD
***************
< CONNECTOR >
* HDJACK 9-885-108-17 CONNECTOR-HDMI (HDMI OUT)
< DIODE >
AD1 9-885-070-27 DIODE DAN202K
AD2 9-885-070-27 DIODE DAN202K
* AZ1 9-885-102-51 DIODE CDS3C30GTH
* AZ3 9-885-102-51 DIODE CDS3C30GTH
* AZ50 9-885-102-51 DIODE CDS3C30GTH
* AZ52 9-885-102-51 DIODE CDS3C30GTH
* AZ55 9-885-102-51 DIODE CDS3C30GTH
* AZ57 9-885-102-51 DIODE CDS3C30GTH
* DOZ1 9-885-102-51 DIODE CDS3C30GTH
QD01 9-885-070-27 DIODE DAN202K
* VZ1 9-885-102-51 DIODE CDS3C30GTH
* VZ3 9-885-102-51 DIODE CDS3C30GTH
* VZ5 9-885-102-51 DIODE CDS3C30GTH
* VZ7 9-885-102-51 DIODE CDS3C30GTH
* VZ10 9-885-102-51 DIODE CDS3C30GTH
* VZ50 9-885-102-51 DIODE CDS3C30GTH
* VZ51 9-885-102-51 DIODE CDS3C30GTH
< FERRITE BEAD >
ABD1 1-400-316-11 CORE-FERRITE BEAD 220ohm
ABD2 1-400-316-11 CORE-FERRITE BEAD 220ohm
ABD3 1-400-316-11 CORE-FERRITE BEAD 220ohm
AVR02 1-400-316-11 CORE-FERRITE BEAD 220ohm
AVR03 1-400-316-11 CORE-FERRITE BEAD 220ohm
AVR19 1-400-316-11 CORE-FERRITE BEAD 220ohm
AVR40 1-400-316-11 CORE-FERRITE BEAD 220ohm
DVR1 9-885-083-84 BEAD-SMD 47ohm
DVR2 9-885-083-84 BEAD-SMD 47ohm
DVR3 9-885-083-84 BEAD-SMD 47ohm
DVR4 9-885-083-84 BEAD-SMD 47ohm
HDR9 1-400-316-11 CORE-FERRITE BEAD 220ohm
HDR10 1-400-316-11 CORE-FERRITE BEAD 220ohm
MR08 9-885-083-84 BEAD-SMD 47ohm
MR18 1-400-316-11 CORE-FERRITE BEAD 220ohm
R851 1-400-316-11 CORE-FERRITE BEAD 220ohm
R852 1-400-316-11 CORE-FERRITE BEAD 220ohm
REM3 1-400-316-11 CORE-FERRITE BEAD 220ohm
REM4 1-400-316-11 CORE-FERRITE BEAD 220ohm
RIS10 9-885-083-84 BEAD-SMD 47ohm
VR100 1-400-316-11 CORE-FERRITE BEAD 220ohm
< FILTER >
DOL1 9-885-069-75 FILTER-EMI SMD
< IC >
AIC4 9-885-070-53 IC 4560 (OP AMP)
AVIC1 9-885-111-37 IC SAA7138HL (VIDEO DECODER)
CIC1 9-885-079-21 IC 74VHC125 (CMOS LOGIC)
IC102 9-885-111-38 IC K4H561638 (DRAM)
IC103 IC (CPRM Key) (Refer to Note 1)
Note 1: Special key has been written in the IC103 (CPRM key),
and therefore the IC103 cannot be replaced.
If this IC is faulty, replace the board entirely.
Note 2: Perform the reset whenever the IC104 was replaced. (See
page 10)
IC104 9-885-111-49 IC ASSY MEMORY (FLASH) (Refer to Note 2)
IC105 1-805-039-11 IC M74HCU04 (CMOS LOGIC)
IC812 9-885-036-96 IC BU4053BCFV (CMOS LOGIC)
IC813 9-885-106-72 IC (AUDIO PROCESSOR)
IC1301 9-885-070-64 IC TSB41AB1-PAP (DATA COMM/GEN)
9 ICHD1 IC TDA9983 (VIDEO PROCESS)
VIC1 9-885-037-03 IC LA73054 (VIDEO)
< TRANSISTOR >
AQ1 9-885-070-34 TRANSISTOR
AQ2 9-885-070-37 TRANSISTOR KSR2103
AQ3 9-885-070-30 TRANSISTOR KSC1623-L
AQ4 9-885-070-34 TRANSISTOR
AQ5 9-885-070-37 TRANSISTOR KSR2103
AQ6 9-885-070-30 TRANSISTOR KSC1623-L
GTR01 9-885-070-30 TRANSISTOR KSC1623-L
GTR02 9-885-070-30 TRANSISTOR KSC1623-L
QMU1 9-885-070-34 TRANSISTOR
QMU2 9-885-070-37 TRANSISTOR KSR2103
QS01 9-885-070-29 TRANSISTOR KSA812
QS02 9-885-070-29 TRANSISTOR KSA812
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
The components identified by mark 9 contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
