Dimensions Pin Assignments
VISCA RS-232C output connector (mini DIN 8-
pin, female)
VISCA RS-422 connector (connector plug,
9-pin)
1
LOCK
JOYSTICK
KNOB
MODE
VALU E
RESET
POSITION
GROUP
MENUGROUP
PRESET
SHIFT
BLACK
LIGHT
PAN -T ILT
RESET
ONE PUSH
AWB
POWER
SELECT
AUTO
MANUAL
AUTO
ONE PUSH
AF
234567
POSITION
CAMERA
GROUP
R
–+
BRIGHT
B
–+
FOCUS
NEAR FAR
1 2 3 4 5 6 7 8
9 10111213141516
145.9
(5
3
/
4
)
137.2
(5
1
/
2
)
391.3 (15
1
/ 2 )
45.9
(1
13
/
16
)
165
(6
1
/2)
30
30
Unit: mm (inches)
Front
Bottom
Side
Top
Pin No. Function
1 No connection
2 No connection
3 TXD IN
4 GND
5 RXD IN
6 GND
7 No connection
8 No connection
Pin No. Function
1 No connection
2 No connection
3 No connection
4 No connection
5 GND
6 RXD IN-
7 RXD IN+
8 TXD IN-
9 TXD IN+
RS-232C
VISCA
19
RS-422
