2-8E
DSC-H50_L2
2-2-6. LCD SECTION
Follow the disassembly in the numerical order given.
1 P Cabinet (C) Assy (470) (1-1 to 1-9)
2 CK-198 Board (2-1 to 2-8)
EXPLODED VIEW
HARDWARE LIST
A
A
1-1
(#1/#14)
1 P Cabinet (C)
Assy (470)
2
CK-198 Board
2-1
2-3
(#1/#14)
HELP11
HELP11
HELP11
HELP12
1-4 (Claw)
1-8
(Claw)
1-7
(#1/#14)
1-6
(#1/#14)
1-5
1-9
1-2
1-3
2-4
2-5
2-6
2-7
(#14)
2-8
2-2
